Green Mini PCIe card with single RJ45 port and silver bracket

LR-LINK

LR-LINK LRES2206PT Mini PCIe Gigabit Ethernet network card

SKU CH-PY29-7QKR3

Mini PCIe single-port Gigabit Ethernet adapter with RJ45 connector and Intel I210 controller for industrial PCs

  • StandardsIEEE 802.3az
  • Speed10/100/1000Mbps
  • Connectors1 x RJ45
  • InterfaceMini PCI Express
  • BUSMini PCIe
  • DriversIncluded
  • Low-profile Mini PCIe design fits compact industrial PCs and single-board computers
  • Intel I210 controller delivers 10/100/1000Mbps wired throughput over a single RJ45 port
  • IEEE 802.3az Energy Efficient Ethernet reduces power draw during low-traffic periods
  • Four transmit and four receive queues per port improve packet handling in multi-tasking workloads
  • Broad OS support covers Windows 7 through 10, Server 2008 R2 through 2019, Linux kernels 2.6.32 or later and VMware ESXi 4.x or later

Compact single-port Ethernet adapter

The LR-LINK LRES2206PT adds one gigabit copper port to embedded systems that expose a Mini PCIe slot. Industrial PCs, single-board computers and digital-multimedia appliances can gain wired connectivity without redesigning the chassis. The card draws little power and supports IEEE 802.3az energy-efficient Ethernet for continuous operation in factory or edge deployments.

Mini PCIe form factor with single RJ45

A single RJ45 jack protrudes from the bracket, so cabling is straightforward in tight enclosures. The Mini PCIe edge connector fits directly into the host board, eliminating the need for riser cables or extra brackets. Drivers ship with the card and cover Windows 7 through 10, Windows Server 2008 R2 to 2019 R2, Linux kernels 2.6.32 and later, plus VMware ESXi 4.x to 6.x.

Rated for 0 °C to 55 °C operation

The Intel I210 controller integrates MAC and PHY, keeping heat output low enough for fanless chassis in the specified temperature range. Four transmit and four receive queues per port help maintain throughput under load without increasing power draw. Humidity tolerance up to 90 % non-condensing suits industrial cabinets and outdoor kiosks alike.

特長

  • Low-profile Mini PCIe design fits compact industrial PCs and single-board computers
  • Intel I210 controller delivers 10/100/1000Mbps wired throughput over a single RJ45 port
  • IEEE 802.3az Energy Efficient Ethernet reduces power draw during low-traffic periods
  • Four transmit and four receive queues per port improve packet handling in multi-tasking workloads
  • Broad OS support covers Windows 7 through 10, Server 2008 R2 through 2019, Linux kernels 2.6.32 or later and VMware ESXi 4.x or later

仕様

BrandLR-LINK
ModelLRES2206PT
StandardsIEEE 802.3az
Speed10/100/1000Mbps
Connectors1 x RJ45
InterfaceMini PCI Express
BUSMini PCIe
DriversIncluded
Temperature0°C ~ 55°C
Humidity0 % ~ 90 % (Non-condensing)

この商品に関する質問

Does the Mini PCIe interface cap throughput below 1000 Mbps?

No, the Mini PCIe bus on this card supports the full 10/100/1000 Mbps speed range and IEEE 802.3az energy-efficient Ethernet.

What physical slot and clearance does the LRES2206PT require?

It needs a Mini PCI Express slot in an industrial PC or single-board computer; the low-profile bracket fits compact chassis.

Which driver step is often missed when installing this adapter on Linux?

Use a kernel of 2.6.32, 3.x, 4.x or later; the included driver package must be compiled against the running kernel headers.
