Small metal box with five RJ45 ports and status LEDs

Netgear Inc.

Netgear Inc. GS305E-100NAS 5-Port Gigabit Smart Switch

SKU CH-112X-FT6XC MPN GS305E-100NAS

A five-port Gigabit smart switch with VLAN, QoS and fanless silent operation for desktop or wall mounting

  • StandardsIEEE 802.3 Ethernet IEEE 802.3ab 1000BASE-T IEEE 802.3u 100B
  • Network Management TypeSmart
  • Primary Ports5 x RJ45
  • Primary Port Speed10/100/1000Mbps
  • MAC Address Table8K
  • Switching MethodStore and Forward

Model GS305E

取り消し線の付いたバージョンは存在しますが、こちらでは取り扱っていません。

  • Silent operation for quiet spaces with fanless design
  • Web-based management simplifies VLAN and QoS setup
  • Five Gigabit ports deliver wire-speed throughput to each device
  • Desktop or wall mounting fits any small-office layout
  • Auto-negotiation and Auto-MDI/MDIX remove cable-matching hassles

5-Port Gigabit Smart Switch

The GS305E-100NAS is a five-port Gigabit Ethernet switch with Easy Smart management features. It targets small office and home office users who need basic network segmentation and traffic prioritisation without the complexity of a fully managed switch.

VLAN, QoS and IGMP Snooping

The switch adds 802.1Q VLAN tagging, 802.1p Class of Service QoS and IGMP Snooping on top of plug-and-play operation. These features let you separate work, home and entertainment traffic, prioritise latency-sensitive applications and optimise multicast streams without requiring additional software installation.

Fanless Desktop or Wall Mount

A fanless design ensures silent operation in noise-sensitive environments such as home offices or meeting rooms. The metal enclosure supports desktop placement or wall and rack mounting using the included hardware. Per-port LEDs show speed, link and activity status while a device-level LED indicates power and system state.

特長

  • Silent operation for quiet spaces with fanless design
  • Web-based management simplifies VLAN and QoS setup
  • Five Gigabit ports deliver wire-speed throughput to each device
  • Desktop or wall mounting fits any small-office layout
  • Auto-negotiation and Auto-MDI/MDIX remove cable-matching hassles

仕様

BrandNETGEAR
Part NumberGS305E-100NAS
StandardsIEEE 802.3 Ethernet
IEEE 802.3ab 1000BASE-T
IEEE 802.3u 100BASE-T
IEEE 802.3ab 1000BASE-T
IEEE 802.1p Class of Service
IEEE 802.1Q VLAN Tagging
IEEE 802.3x Full-duplex Flow Control
Network Management TypeSmart
Primary Ports5 x RJ45
Primary Port Speed10/100/1000Mbps
MAC Address Table8K
Switching MethodStore and Forward
VLAN SupportYes
Jumbo Frames9KB
Buffer Memory128KB
ProtocolsTCP/IP
PoENo
QoSYes
Layer2
Port MirroringYes
LEDsPer port: Speed, Link, Activity
Per device: Power, system
TemperatureOperating Temperature: 0 ~ 50 degree Celsius (32 ~ 122 degree Fahrenheit)
Storage Temperature: -20 ~ 70 degree Celsius (-4 ~ 158 degree Fahrenheit)
HumidityOperating Humidity: 90% maximum relative humidity (RH), non-condensing
Storage Humidity: 95% maximum relative humidity (RH), non-condensing
FeaturesEnable network configuration and management at the price point of Unmanaged Switches
Simple, yet useful network set-up on top of plug-and-play connectivity
Flexible management via easy-to-use web browser-based management GUI or using the PC-based Utility application
VLAN support for traffic segmentation
Quality of Service (QoS) for traffic prioritization
Auto "denial-of-service" (DoS) prevention
Troubleshoot connection issues via cable test
Loop detection and broadcast storm controls
Rate limiting for better bandwidth allocation
Port mirroring for network monitoring
Jumbo frame suppo
配送重量0.56 kg
梱包サイズ244 × 155 × 71 mm

このモデルの他のバージョン

同シリーズにさらに 3点

同じファミリーで、メモリ・クーラー・クロックが異なります — 購入前に比較してください。

この商品に関する質問

Does the fanless design need any periodic cleaning or internal maintenance?

The switch has no fan and no moving parts, so no internal cleaning is required; only keep the vents clear of dust.

With 128 KB buffer and 9 KB jumbo frames, which limit is reached first during sustained full-duplex traffic?

The 128 KB buffer fills before jumbo-frame size becomes a constraint, so burst absorption is the practical ceiling.

How much heat does the silent metal case add to a closed cabinet running all day?

Fanless operation means all waste heat radiates from the enclosure; ensure cabinet airflow keeps ambient temperature below 50 °C.
