Green 204-pin DDR3L SODIMM module with black chips, no heat spreader

OWC

OWC 8GB DDR3L 1600 PC3L-12800 CL11 2Rx8 204-pin 1.35V Non-ECC SODIMM for HP TouchSmart 15 Series

SKU CH-6NSN-TTJHC

8 GB DDR3L SODIMM running at 1600 MHz with CL11 latency and 1.35 V for HP TouchSmart 15 series laptops

  • Capacity8GB
  • Type204-Pin DDR3L Non-ECC SODIMM
  • SpeedDDR3L 1600 (PC3L 12800)
  • CAS LatencyCL11
  • Voltage1.35V
  • ECCNo
  • Boost multitasking with 8GB DDR3L 1600 SODIMM
  • Low 1.35V operation cuts power draw and heat
  • CL11 latency delivers responsive system performance
  • 204-pin unbuffered design fits HP TouchSmart 15 Series
  • JEDEC and RoHS compliant for warranty-safe upgrade

HP TouchSmart 15 DDR3L upgrade

This OWC module is an 8GB DDR3L SODIMM built to the PC3L-12800 standard at 1600MHz with CL11 latency. It operates at the JEDEC low-voltage level of 1.35V and uses an unbuffered, non-ECC 2Rx8 layout on a 204-pin form factor. The part is validated specifically for HP TouchSmart 15 series notebooks that use DDR3 memory.

Suitable for single-slot capacity increases

Owners of a compatible TouchSmart 15 who have a free SODIMM slot can install this module to raise total system memory by 8GB. It will not help users whose laptop is already at the manufacturer's maximum supported capacity or whose chassis provides no accessible memory slot. Buyers needing ECC error correction or registered buffering must choose a different product.

204-pin DDR3L SODIMM form factor

The module fits only sockets designed for 204-pin DDR3L SO-DIMMs running at 1.35V. A 204-pin DDR3 module rated for 1.5V is electrically incompatible and should not be used. Verify the service manual for your exact TouchSmart 15 model to confirm the slot type and voltage requirement before purchase.

特長

  • Boost multitasking with 8GB DDR3L 1600 SODIMM
  • Low 1.35V operation cuts power draw and heat
  • CL11 latency delivers responsive system performance
  • 204-pin unbuffered design fits HP TouchSmart 15 Series
  • JEDEC and RoHS compliant for warranty-safe upgrade

仕様

BrandOWC
Part Number1S6T32R808GB
Capacity8GB
Type204-Pin DDR3L Non-ECC SODIMM
SpeedDDR3L 1600 (PC3L 12800)
CAS LatencyCL11
Voltage1.35V
ECCNo
Buffered/RegisteredUnbuffered
Rank2Rx8
Heat SpreaderNo
Compatible SystemHP TouchSmart 15 Series using DDR3 Memory

このモデルの他のバージョン

同シリーズにさらに 5点

同じファミリーで、メモリ・クーラー・クロックが異なります — 購入前に比較してください。

この商品に関する質問

My HP TouchSmart 15 has an empty SODIMM slot — will this 204-pin DDR3L 1600 module fit and work?

This module is a 204-pin DDR3L SODIMM rated at 1600MHz CL11 1.35V, built to JEDEC standard for the HP TouchSmart 15 Series using DDR3 memory.

Will this 8GB DDR3L 1600 CL11 stick run reliably next to the original 4GB DDR3L 1600 module already in my TouchSmart 15?

Both modules share the same DDR3L 1600 CL11 1.35V specification, so the system will operate them at the common speed and timing.

After installing the module, how can I verify it is running at the rated 1600MHz CL11 1.35V?

Open Task Manager's Performance tab or run CPU-Z; both will show the memory operating at 800MHz (DDR3-1600) with CL11 timings at 1.35V.
