Silver 12.1-inch fanless all-in-one panel PC with resistive touchscreen

partaker

partaker A2-PA-121TPC-CE5B(I54) 12.1" all-in-one PC i5 1.60GHz 8GB DDR3 128GB SSD

SKU CH-KGM7-4WG47

A 12.1" industrial panel PC with IP65 front protection, Intel Core i5 1.60GHz, 8GB DDR3L, 128GB SSD and a high-temperature five-wire resistive touchscreen

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 4th Gen
  • CPU Name1.60GHz
  • GPU/VGA TypeIntel HD Graphics 4400

GPU Intel HD Graphics 4400

Memory 8GB DDR3

SSD

HDD None

  • None
  • 1TB

取り消し線の付いたバージョンは存在しますが、こちらでは取り扱っていません。

  • IP65 front panel resists dust and water jets
  • Fanless aluminium chassis runs silently from 0 to 50 °C
  • Intel Core i5 4th Gen at 1.60 GHz with 8 GB DDR3L
  • 128 GB SSD plus mSATA and 2.5" SATA bays for expansion
  • 1" 1024×768 resistive touch rated for 200 million touches

12.1" Industrial Panel PC with i5

This 12.1 inch all-in-one system uses an Intel Core i5 4th Gen processor at 1.60GHz with 8GB DDR3L memory and a 128GB SSD. The fanless aluminium chassis carries an IP65-rated front panel and a high-temperature five-wire resistive touchscreen running at 1024 x 768 resolution. Windows 10 Pro is pre-installed on the compact embedded unit. ||

Suited for embedded industrial use

The unit fits embedded, wall-mounted, desktop or cantilevered installations with a 301 x 229mm cut-out and VESA 75 mounting. It operates from 0 to 50°C with the SSD installed and accepts 100-240V AC input via a 12V DC supply. Buyers who need a larger display, higher brightness than 350 cd/m², or a different touch technology should consider other form factors. ||

Single SODIMM slot caps RAM at 8GB

Memory is provided by one SODIMM DDR3L module running at 1333/1600 MT/s, and the manufacturer states the maximum is 8GB. No further expansion is possible beyond this limit. Storage can be added through the internal mSATA slot or a 2.5 inch SATA bay, but the memory ceiling is fixed by the single slot design.

特長

  • IP65 front panel resists dust and water jets
  • Fanless aluminium chassis runs silently from 0 to 50 °C
  • Intel Core i5 4th Gen at 1.60 GHz with 8 GB DDR3L
  • 128 GB SSD plus mSATA and 2.5" SATA bays for expansion
  • 1" 1024×768 resistive touch rated for 200 million touches

仕様

ModelA2-PA-121TPC-CE5B(I54)-8G128G
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 4th Gen
CPU Name1.60GHz
GPU/VGA TypeIntel HD Graphics 4400
Memory Capacity8GB DDR3
HDDNo
Screen Size12.1"
TouchscreenYes

このモデルの他のバージョン

同シリーズにさらに 5点

同じファミリーで、メモリ・クーラー・クロックが異なります — 購入前に比較してください。

この商品に関する質問

Should I choose the 8GB DDR3L 1333/1600 configuration or add more memory?

The board has one SODIMM slot and supports up to 8GB, so the installed 8GB DDR3L module already reaches the maximum capacity.

How does the 1.60GHz Core i5 4th Gen perform in a fanless industrial chassis?

The aluminium alloy housing dissipates heat passively, allowing the 1.60GHz processor to run continuously within the 0–50°C operating range without throttling.

What does the Mini PCIe slot with SIM holder actually allow me to add?

It accepts a full-size Mini PCIe card such as a Wi-Fi or 4G LTE module; the adjacent SIM slot provides cellular connectivity for remote deployments.
