17 inch industrial all-in-one panel PC flat touchscreen aluminium fanless enclosure

partaker

partaker A21-New-I5-10310U-32G1TBSSD 17" all-in-one PC

SKU CH-ZTXE-AZ0A1

17-inch fanless all-in-one with IP65 front, Core i5-10310U, 32 GB DDR4, 1 TB SATA SSD and Windows 11 Pro

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i5 10th Gen
  • GPU/VGA TypeIntel UHD Graphics
  • Memory Capacity32GB DDR4
  • Maximum Memory Supported32 GB

CPU Type Intel Core i5 10th Gen

Memory Capacity 32GB DDR4

SSD 1TB

  • IP65 front panel resists dust and water jets
  • Intel Core i5-10310U up to 4.40 GHz for demanding tasks
  • 32 GB DDR4 and 1 TB SSD deliver fast, responsive performance
  • Fanless aluminium chassis runs silently in noise-sensitive areas
  • 9–36 V DC Phoenix input suits industrial power environments

17-inch IP65 industrial all-in-one

This 17-inch all-in-one panel PC combines an Intel Core i5-10310U processor with 32GB of DDR4 memory and a 1TB SATA SSD inside a fanless aluminium chassis. The front panel carries an IP65 rating and a multi-touch resistive screen running at 1280 x 1024 resolution. Windows 11 Pro is pre-installed for immediate deployment.

Replaces legacy panel PCs and fan-cooled units

The fanless design removes moving parts that fail in dusty or vibration-prone environments, while the 9 V to 36 V wide-range Phoenix power input suits unstable industrial supplies. Dual Intel gigabit LAN ports, two configurable COM ports and HDMI video output cover common automation and SCADA connectivity without extra adapters. The jump is worth it when silent 7×24 operation and front-panel water resistance are mandatory.

32GB DDR4 and 1TB SATA headroom

The single SODIMM slot is already populated to the 32GB maximum, so memory expansion is not possible. Storage headroom remains via an internal 2.5-inch SATA bay that supports a second SSD or HDD with RAID 0 or 1, and an M.2 2280 SATA slot already occupied by the boot drive. The Mini PCIe slot with SIM holder adds 4G or Wi-Fi connectivity for remote sites.

特長

  • IP65 front panel resists dust and water jets
  • Intel Core i5-10310U up to 4.40 GHz for demanding tasks
  • 32 GB DDR4 and 1 TB SSD deliver fast, responsive performance
  • Fanless aluminium chassis runs silently in noise-sensitive areas
  • 9–36 V DC Phoenix input suits industrial power environments

仕様

ModelA21-New-I5-10310U-32G1TBSSD
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i5 10th Gen
GPU/VGA TypeIntel UHD Graphics
Memory Capacity32GB DDR4
Maximum Memory Supported32 GB
SSD1TB
HDDNo
Screen Size17"
TouchscreenYes

このモデルの他のバージョン

同シリーズにさらに 5点

同じファミリーで、メモリ・クーラー・クロックが異なります — 購入前に比較してください。

この商品に関する質問

What cut-out size does the 17-inch A21 need for embedded mounting?

The panel requires a 389 x 321 mm rectangular cut-out for embedded installation, matching the front IP65 bezel dimensions.

Which step is often missed when wiring the 9-36V Phoenix connector on this unit?

Polarity must be observed on the 2-pin Phoenix plug; reversing the wide-range DC input will prevent power-up.

What storage upgrades are possible later on the A21 with its 1 TB M.2 SATA drive?

You can add a 2.5-inch SATA SSD or HDD in the second bay and configure RAID 0 or 1 across both drives.
