Gray aluminum 15 inch IP65 resistive touch panel PC

partaker

partaker A27 15" IP65 resistive touch i5-7200U 16GB 512GB AI edge system

SKU CH-BW8E-D5MHH

A 15 inch IP65 resistive touch panel PC with i5-7200U, 16GB DDR4 and 512GB storage for industrial edge AI workloads

  • TypeAll-in-One PC
  • Form FactorAll-in-One
  • ColorGray
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 7th Gen
  • CPU NameIntel Core i5-7200U

A27 15" Resistive I5 7200U 16GB RAM / 512GB SSD

  • IP65 front panel resists dust and water ingress
  • Fanless aluminium chassis runs silently without moving parts
  • Intel Core i5-7200U up to 3.10 GHz handles edge workloads
  • 16 GB DDR4 and 512 GB storage support AI tasks
  • Dual Gigabit LAN plus four USB and two COM ports

Industrial Panel PC

The Partaker A27 is a 15 inch all-in-one system with an IP65-rated front panel and a resistive touchscreen rated to 50 million touches. It runs Windows 10 Pro on an Intel Core i5-7200U processor with 16 GB of DDR4 memory and a 512 GB mSATA drive. The fanless aluminium chassis operates silently from -20 to +60 °C.

Interface Limits

Dual Gigabit Ethernet ports provide wired networking while two mini PCIe slots accept optional Wi-Fi, Bluetooth, 3G or 4G modules with a SIM holder. Video output uses a single HDMI port alongside the internal LVDS connection for synchronous or asynchronous dual-display operation. Two COM ports support RS232 or RS485 and can be expanded to six, while four USB ports and an audio jack handle peripherals.

Pre-Order Checks

Verify that the 355 mm by 279 mm panel cutout matches your enclosure and that a 12 V DC supply (or optional 9–36 V wide-range input) is available. Confirm the resistive touchscreen suits your application, as capacitive touch is a factory option. Ensure the 1024 x 768 resolution and 4:3 aspect ratio meet your software requirements. Check whether the two DDR4 slots (32 GB maximum) and single mSATA bay provide sufficient headroom for future upgrades.

特長

  • IP65 front panel resists dust and water ingress
  • Fanless aluminium chassis runs silently without moving parts
  • Intel Core i5-7200U up to 3.10 GHz handles edge workloads
  • 16 GB DDR4 and 512 GB storage support AI tasks
  • Dual Gigabit LAN plus four USB and two COM ports

仕様

TypeAll-in-One PC
Form FactorAll-in-One
ColorGray
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 7th Gen
CPU NameIntel Core i5-7200U
Screen Size15"
Screen TypeMulti-Touch Screen

このモデルの他のバージョン

同シリーズにさらに 5点

同じファミリーで、メモリ・クーラー・クロックが異なります — 購入前に比較してください。

この商品に関する質問

Should I pick the 16 GB / 512 GB configuration or plan for the 32 GB maximum?

The unit ships with 16 GB DDR4 and a 512 GB mSATA drive; the board accepts up to 32 GB across two slots if your workloads need more memory headroom.

How does the i5-7200U at 3.10 GHz perform inside this fanless chassis?

The dual-core processor runs up to 3.10 GHz within a sealed aluminum alloy shell, so sustained loads stay silent but rely on passive cooling rather than active airflow.

What does the dual Gigabit Ethernet and dual COM layout actually support?

Two Realtek Gigabit ports handle network wake-up and PXE boot, while two configurable RS232/485 COM ports can be expanded to six for legacy industrial devices.
