15 inch IP65 industrial all-in-one with aluminium fanless chassis and projected capacitive touchscreen

partaker

partaker A4 15" IP65 i5-1135G7 32GB DDR4 1TB SSD

SKU CH-NHQ4-36G4B

A 15-inch IP65-rated industrial all-in-one PC with 10-point capacitive touchscreen, Intel Core i5-1135G7 processor, 32GB DDR4 memory and 1TB SSD storage

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i5 11th Gen
  • GPU/VGA TypeIntel Iris Xe Graphics
  • Memory Capacity32GB DDR4
  • SSD1TB

Memory Capacity 32GB DDR4

  • 16GB DDR4
  • 32GB DDR4
  • 8GB DDR4

SSD 1TB

HDD None

  • 1TB
  • None

取り消し線の付いたバージョンは存在しますが、こちらでは取り扱っていません。

  • IP65 front-panel protection resists dust and water jets in harsh environments
  • 10-point projected capacitive touchscreen enables precise multi-touch control
  • Intel Core i5-1135G7 up to 4.20 GHz delivers reliable performance for continuous operation
  • Fanless aluminium alloy cooling runs silently with zero moving parts
  • 32 GB DDR4 and 1 TB SSD provide ample memory and fast storage

Industrial 15" Panel PC

The Partaker A4 is a 15-inch all-in-one computer built for industrial settings. It combines an IP65-rated front panel, 10-point projected capacitive touchscreen, and fanless aluminium cooling in a compact chassis. The system ships with Windows 11 Pro, 32 GB of DDR4-3200 memory, and a 1 TB SSD ready for deployment. It targets automation, kiosk, and control-room installations that demand sealed, silent operation.

Sustained-load behaviour

Fanless aluminium cooling dissipates heat without moving parts, keeping the system silent during continuous 24/7 duty. The Intel Core i5-1135G7 processor runs at up to 4.20 GHz within a 0–50 °C operating range when an SSD is fitted. A hardware watchdog timer with 255 levels can trigger automatic power-on after a failure, supporting unattended reliability. No airflow clearance is required beyond the embedded mounting cut-out.

Interface practical limits

Video output is provided through one HDMI and one VGA port, driving the internal 1024 x 768 panel and an external display. Networking uses two wired LAN ports; wireless or 5G can be added via the internal M.2 Key E and Key B slots. Storage expansion allows one M.2 2260/2280 PCIe x1 or SATA drive plus one 2.5-inch SATA device. Memory tops out at 64 GB across two SODIMM slots.

特長

  • IP65 front-panel protection resists dust and water jets in harsh environments
  • 10-point projected capacitive touchscreen enables precise multi-touch control
  • Intel Core i5-1135G7 up to 4.20 GHz delivers reliable performance for continuous operation
  • Fanless aluminium alloy cooling runs silently with zero moving parts
  • 32 GB DDR4 and 1 TB SSD provide ample memory and fast storage

仕様

ModelA4-PA-150TPC-CE6A(I5B)-32G1TBSSD
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i5 11th Gen
GPU/VGA TypeIntel Iris Xe Graphics
Memory Capacity32GB DDR4
SSD1TB
HDDNo
Screen Size15"
TouchscreenYes

このモデルの他のバージョン

同シリーズにさらに 5点

同じファミリーで、メモリ・クーラー・クロックが異なります — 購入前に比較してください。

この商品に関する質問

How much heat and noise does the fanless aluminum alloy cooling produce during 24/7 operation?

The fanless aluminum alloy cooling runs silently with no moving parts, making it suitable for continuous round-the-clock industrial use.

Which power input and mounting hardware must I already have to install this panel PC?

It requires a 12 V DC supply (100-240 V AC adapter included) and a cut-out of 348 x 272 mm for embedded mounting; wall, desktop or cantilever brackets are not supplied.

Will the VGA and COM ports on this unit work with my existing legacy PLCs and displays?

Yes, the native VGA output and two COM ports provide direct connectivity for older industrial equipment without adapters.
