Silver 1U rackmount server chassis with eight front drive bays

ASRock Rack

ASRock Rack 1U4L4E-ICX/2T 1U barebone server 4 NVMe 4 SATA bays

SKU CH-0N3J-1R8HT MPN 1U4L4E-ICX/2T

1U rackmount barebone supporting one 3rd Gen Intel Xeon Scalable processor, eight DDR4 DIMM slots, dual 10GbE LAN, four 2.5" NVMe/SATA and four 3.5" SATA hot-swap bays.

  • Form Factor1U Rackmount
  • WorkloadGeneral Purpose Server
  • CPU TypeSupports 3rd Gen Intel Xeon Scalable processors
  • CPU SocketLGA 4189
  • Installed CPUNo CPU Installed
  • Max Processors1
  • High-density storage with four 2.5" NVMe and four 3.5" SATA hot-swap bays
  • Redundant power from 1+1 Platinum 750W supplies keeps the server running
  • 10 Gigabit networking via dual Intel X710-AT2 ports for fast data transfer
  • Scalable memory with eight DDR4 slots supporting RDIMM, LRDIMM and Optane 200 series
  • Flexible expansion using one full-height PCIe 4.0 x16 slot for accelerators or NICs

1U barebone for Xeon Scalable servers

This 1U rackmount barebone accepts a single 3rd Gen Intel Xeon Scalable processor in an LGA 4189 socket. Eight DDR4 DIMM slots support RDIMM, LRDIMM, 3DS and Intel Optane Persistent Memory 200 series modules. It targets general-purpose workloads such as database processing and storage in data-centre or SMB environments.

Redundant Platinum 750 W power with front airflow

A 1+1 Platinum 750 W slim PSU pair provides redundancy while drawing cool air through the front hot-swap bays. The Aspeed AST2500 BMC with 16 MB video memory handles IPMI over a dedicated RJ45 port, keeping management traffic separate from the dual 10 GbE Intel X710-AT2 links.

Mixed NVMe and SATA bays plus PCIe 4.0 x16

Four 2.5-inch bays accept NVMe PCIe 3.0 x4 or SATA drives, while four 3.5-inch bays take SATA drives, all hot-swappable. A full-height half-length PCIe 4.0 x16 slot is available via the RB1UX16_G4 riser, and an M.2 slot supports PCIe 3.0 x4 or SATA 6 Gb/s. Builders needing more than one CPU socket or more than eight memory channels should look elsewhere.

주요 특징

  • High-density storage with four 2.5" NVMe and four 3.5" SATA hot-swap bays
  • Redundant power from 1+1 Platinum 750W supplies keeps the server running
  • 10 Gigabit networking via dual Intel X710-AT2 ports for fast data transfer
  • Scalable memory with eight DDR4 slots supporting RDIMM, LRDIMM and Optane 200 series
  • Flexible expansion using one full-height PCIe 4.0 x16 slot for accelerators or NICs

사양

BrandASRock Rack
Model1U4L4E-ICX/2T
Form Factor1U Rackmount
WorkloadGeneral Purpose Server
CPU TypeSupports 3rd Gen Intel Xeon Scalable processors
CPU SocketLGA 4189
Installed CPUNo CPU Installed
Max Processors1
North BridgeIntel C621A
Memory Slots8 x 288Pin
Installed Memory SizeNo Memory Installed
Memory Type SupportedSupports DDR4 288-pin RDIMM, LRDIMM, RDIMM/LRDIMM-3DS, Intel Optane Persistent Memory 200 series
Installed HDDNo Storage Installed
GPU/VPUAspeed AST2500
Video Memory16MB
PCI Express1 FHHL PCIe4.0 x16 via RB1UX16_G4
First LANIntel X710-AT2
Max. LAN Speed10 Gigabit
Hot-Swap Bays4 Hot-swap 2.5" NVMe (PCIe3.0 x4)/SATA drive bays, 4 Hot-swap 3.5" SATA drive bays
VGA1
Rear USB2 x USB 3.2 Gen 1 Type-A
RJ452 x RJ45 (10GbE), 1 dedicated IPMI
Max. Power1+1 Platinum 750W Slim PSU
TemperatureOperation temperature: 10°C ~ 35°C
Non operation temperature: -40°C ~ 70°C
HumidityNon operation humidity: 20% ~ 90% ( Non condensing)
Dimensions26.63" x 17.24" x 1.71"
배송 무게22.50 kg
포장 크기965 × 635 × 229 mm

이 상품에 대한 질문

How do I install the CPU and what step is often missed?

Install a 3rd Gen Intel Xeon Scalable processor into the LGA 4189 socket; the step often missed is applying thermal paste and securing the heatsink before powering on.

What maintenance or replacement will the power supply need later?

The 1+1 Platinum 750W Slim PSU modules are hot-swap; a failed unit can be replaced without shutting down the server.

What limit appears first under sustained heavy storage workloads?

The four 2.5" NVMe bays run at PCIe3.0 x4 each, so aggregate NVMe bandwidth caps before the single PCIe4.0 x16 slot or 10 Gigabit LAN.
