White rectangular surveillance camera with dual sensor lenses and IR ring, 88 by 133 by 208 mm

Axis Communications

Axis Communications 02416-001 P4707-PLVE dual-sensor 2×5 MP network camera

SKU CH-G5GE-XBZNE MPN 02416-001

Dual-sensor panoramic camera captures two 5 MP views with 360° IR illumination and 2.5x optical zoom

  • Bundled Camera Number2 Cameras
  • Network CameraYes
  • TypeSurveillance Camera
  • Connection TypeShielded RJ45 10BASE-T/100BASE-TX/1000BASE-T PoE 3.5 mm mic/
  • ColorBlack / White
  • Mounting LocationYes
  • Two 5 MP sensors cover a wide area with one IP address
  • 360° IR illumination with controllable LEDs gives clear night images
  • 5× optical zoom lets you switch between overview and detail
  • Deep-learning analytics run on both sensors at the edge
  • Lightfinder and Forensic WDR preserve colour and detail in mixed light

Dual-sensor 2×5 MP panoramic camera

The Axis P4707-PLVE combines two 1/2.7" progressive scan RGB CMOS sensors into a single IP address, delivering 2×5 MP at 4:3 or 2×Quad HD at 16:9. It suits installers who need wide-area coverage and detailed zoom from one mounting point.

2.5× optical zoom with 360° IR illumination

Varifocal 3.3–8.1 mm lenses provide horizontal fields of view from 98° down to 36° and vertical fields from 69° down to 27°. 360° IR LEDs with individual control extend usable imaging into complete darkness, while Lightfinder and Forensic WDR preserve colour and detail in mixed lighting.

MicroSD slot with AES-XTS encryption and NAS

A microSD/microSDHC/microSDXC card slot supports hardware encryption (AES-XTS-Plain64 256-bit) for local storage redundancy. The camera also records directly to network-attached storage, and ONVIF compliance allows integration with third-party video management systems.

주요 특징

  • Two 5 MP sensors cover a wide area with one IP address
  • 360° IR illumination with controllable LEDs gives clear night images
  • 5× optical zoom lets you switch between overview and detail
  • Deep-learning analytics run on both sensors at the edge
  • Lightfinder and Forensic WDR preserve colour and detail in mixed light

사양

BrandAXIS
SeriesAxis P47 Series
ModelP4707-PLVE
Part Number02416-001
Bundled Camera Number2 Cameras
Network CameraYes
TypeSurveillance Camera
Connection TypeShielded RJ45 10BASE-T/100BASE-TX/1000BASE-T PoE
3.5 mm mic/line in
ColorBlack / White
Mounting LocationYes
Micro SD SlotSupport for microSD/microSDHC/microSDXC card
Support for SD card encryption (AES-XTS-Plain64 256bit)
Recording to network-attached storage (NAS)
For SD card and NAS recommendations see axis.com
ONVIFYes
Pan/TiltPan ±110°, tilt ±75°, rotation ±170°
Sensor & Detector2 x 1/2.7” progressive scan RGB CMOS
HD Resolution4:3: 2x 2592x1944 (2x 5MP) to 2x 640x480
16:9: 2x 2560x1440 (2x Quad HD) to 2x 640x360
Lens TypeVarifocal, 3.3–8.1 mm, F1.9–3.2
Horizontal field of view: 98°–36°
Vertical field of view: 69°–27°
Diagonal field of view: 133°–46°
Minimum focus distance: 0.5 m (1.6 ft)
Fixed iris, IR corrected, remote zoom and focus
Optical Zoom2.5x Optical Zoom
Power over EthernetYes
DimensionHeight: 88 mm (3.5 in)
Width: 133 mm (5.2 in)
Length: 208 mm (8.2 in)
Weight975 g (2.1 lb)
Package ContentsInstallation guide, Windows
decoder 1-user license, connector
kit, weathershield, connector guard
배송 무게1.36 kg
포장 크기231 × 188 × 109 mm

이 상품에 대한 질문

Will the Axis P4707-PLVE connect to my existing PoE switch without extra cabling?

The camera uses a shielded RJ45 port supporting 10BASE-T, 100BASE-TX and 1000BASE-T Power over Ethernet, so it draws power and data over a single network cable from any standard PoE switch.

How do I verify both 5 MP sensors are streaming correctly after installation?

Log into the web interface; each sensor appears as a separate 2592x1944 or 2560x1440 video channel at up to 30 fps, and the ONVIF device info page confirms dual-stream operation.

What mounting hardware and storage media are included in the box?

The unit ships with mounting brackets for wall or ceiling installation; a microSD, microSDHC or microSDXC card for local recording must be purchased separately.
