Compact silver metal mini PC with front ports and antennas

BFKK

BFKK i5-3317U 8GB 512GB Fanless Industrial Mini PC

SKU CH-0GW7-6491V

Fanless industrial mini PC with an Intel i5-3317U dual-core processor, 8GB DDR3L RAM, 512GB mSATA SSD, dual Gigabit LAN ports, four RS232 serial ports, and four USB 3.0 ports

  • CPU TypeIntel i5

Options 8GB+512GB

  • Fanless design ensures silent operation with full metal case
  • Intel i5-3317U dual-core processor reaches 2.6 GHz turbo frequency
  • 8 GB DDR3L memory and 512 GB SATA SSD provide responsive performance
  • Two 82574L Gigabit LAN ports plus four COM RS232 ports for industrial connectivity
  • HD Graphics 4000 with 1.05 GHz max dynamic frequency drives display output

Fanless Industrial Mini PC with i5-3317U

This fanless mini PC uses an Intel Core i5-3317U dual-core processor running at 1.7 GHz base and 2.6 GHz turbo with 3 MB cache. It ships with 8 GB of DDR3L memory and a 512 GB mSATA SSD inside a full metal chassis. Windows 11 Pro is pre-installed for immediate deployment.

Suited for embedded and industrial roles needing

The system provides four RS232 COM ports and dual Intel 82574L Gigabit LAN ports for reliable wired networking. Four USB 3.0 and four USB 2.0 ports handle peripheral connections. HD Graphics 4000 drives displays through HD and VGA outputs. Buyers who require more than 8 GB of RAM, a larger internal drive, additional display outputs or wireless networking should look at a different platform.

Key spec: 512 GB mSATA SSD and 8 GB DDR3L soldered

Storage uses the mSATA form factor and memory is not expandable beyond the installed 8 GB. Verify that your application fits within these fixed capacities before purchase. The package includes a power adapter, US power cable, HD cable, antennas and SATA data and power cables for an extra drive.

주요 특징

  • Fanless design ensures silent operation with full metal case
  • Intel i5-3317U dual-core processor reaches 2.6 GHz turbo frequency
  • 8 GB DDR3L memory and 512 GB SATA SSD provide responsive performance
  • Two 82574L Gigabit LAN ports plus four COM RS232 ports for industrial connectivity
  • HD Graphics 4000 with 1.05 GHz max dynamic frequency drives display output

사양

CPU TypeIntel i5

이 모델의 다른 버전

같은 라인업에서 2개 더

같은 제품군에서 메모리·쿨러·클럭이 다릅니다 — 결정 전에 비교해 보세요.

이 상품에 대한 질문

What does the i5-3317U dual-core processor cap at for turbo frequency?

The i5-3317U reaches a maximum turbo frequency of 2.6 GHz with its two cores and four threads.

What physical space and mounting does the full metal fanless case require?

The sealed metal chassis dissipates heat without a fan, so it only needs a flat surface or VESA bracket with enough airflow clearance around the fins.

How is the mSATA SSD installed, and which cable step is often missed?

Slide the 512 GB mSATA drive into the onboard slot, secure it with the included screw, then attach both the supplied SATA data and power cables before closing the case.
