Green circuit board with ten black SATA ports and PCIe connector

EN-Labs

EN-Labs 10 Port SATA 3.0 PCIe Card ASM1166

SKU CH-92BJ-9Z5Q6

Adds ten SATA 3.0 ports via PCIe using an ASM1166 controller for software RAID arrays

  • Adds ten SATA 3.0 ports via PCIe 4x lane
  • ASMedia ASM1166 chipset runs stable at high temps
  • Delivers 6 Gbps SATA throughput per drive
  • Works with Windows 10, Linux, Synology, Ubuntu
  • Includes full-profile and low-profile mounting brackets

PCIe 4x to 10 Port SATA 3.0 Controller

This EN-Labs expansion card adds ten SATA 3.0 ports to a system through a single PCIe 4x slot. It uses the ASMedia ASM1166 chipset for stable operation and includes both full-profile and low-profile brackets for flexible installation. The card supports 6 Gbps data transfer speeds and features LED indicators for drive status monitoring.

Suited for storage expansion without hardware RAID

Builders needing additional SATA connections for hard drives, SSDs or optical drives on Windows, Linux or Synology platforms will find this card suitable. It operates in software RAID modes only. Buyers who require a dedicated hardware RAID engine with onboard cache or battery backup should look at a different class of controller.

ASMedia ASM1166 chipset defines capability

The ASM1166 chipset provides the ten native SATA 3.0 ports and determines the card's lack of hardware RAID support. It also governs the plug-and-play compatibility across the listed operating systems. This single component decides whether the card matches the required storage topology.

주요 특징

  • Adds ten SATA 3.0 ports via PCIe 4x lane
  • ASMedia ASM1166 chipset runs stable at high temps
  • Delivers 6 Gbps SATA throughput per drive
  • Works with Windows 10, Linux, Synology, Ubuntu
  • Includes full-profile and low-profile mounting brackets

사양

이 상품에 대해 아직 공개된 사양이 없습니다.

이 상품에 대한 질문

Does the ASM1166 chipset run hot or noisy when all 10 SATA 3.0 ports are active for long periods?

The ASM1166 chipset is designed for enhanced heat dissipation and stable high-temperature operation; the card has no fan, so it adds no audible noise.

What cables or brackets must I already have to install this 10-port SATA card?

You need ten SATA data cables and a free PCIe x4 slot; both full-profile and low-profile brackets are included for case mounting.

Will this SATA 3.0 card work in an older system that only has PCIe 2.0 slots?

The card uses a PCIe x4 interface and will function in a PCIe 2.0 slot at the slot's native speed; software RAID and all 10 ports remain usable.
