White Micro ATX case with tempered glass side panel and brushed aluminium front I/O

JONSBO

JONSBO D33 White Micro ATX PC Case

SKU CH-QHS2-MJBJB

A white Micro ATX chassis with a tempered glass side panel, magnetic front grille and nine fan positions supports 360 mm top radiators, 435 mm graphics cards and 172 mm CPU coolers

  • Motherboard CompatibilityMicro ATX / Mini-ITX/MATX BTF
  • ColorWhite
  • Case MaterialAluminum / Steel / Plastic / Tempered Glass
  • TypeMicro ATX / Mini-ITX
  • Side Panel1 x Side Tempered Glass Panel
  • Front PortsUSB3.2 Gen2 Type-C*1/USB3.0*2/AUDIO*1+MIC*1(2 in 1)

D33 STD D33 WHITE

D33 WD D33 WD/WHT

  • High airflow from nine optional fan positions
  • Top-mounted 360 mm radiator support for liquid cooling
  • Fits graphics cards up to 435 mm long
  • USB 3.2 Gen 2 Type-C front port for fast connectivity
  • Tempered glass side panel shows internal components

JONSBO D33 White Micro ATX Case

The JONSBO D33 White is a Micro ATX and Mini-ITX chassis finished in white with a tempered glass side panel. It provides nine optional fan positions and supports a 360 mm radiator on the top. The front I/O includes a USB3.2 Gen2 Type-C port, two USB3.0 ports and a combined audio jack. Builders get two 3.5-inch and two 2.5-inch drive bays plus four expansion slots.

Suits compact high-airflow builds.

This case suits builders who want a compact Micro ATX or Mini-ITX system with strong cooling headroom and support for MATX BTF motherboards. It is not for users who need E-ATX motherboard compatibility or more than four expansion slots. Buyers requiring more than two 3.5-inch drive bays should look at larger chassis. The 160 mm power-supply length limit also rules out some longer ATX units.

435 mm maximum graphics-card length

The single specification that decides fitment is the 435 mm maximum graphics-card length. Any card longer than this will not install regardless of cooler or power-supply choice. This dimension also determines whether a triple-fan flagship model can be used in the build.

주요 특징

  • High airflow from nine optional fan positions
  • Top-mounted 360 mm radiator support for liquid cooling
  • Fits graphics cards up to 435 mm long
  • USB 3.2 Gen 2 Type-C front port for fast connectivity
  • Tempered glass side panel shows internal components

사양

Motherboard CompatibilityMicro ATX / Mini-ITX/MATX BTF
ColorWhite
Case MaterialAluminum / Steel / Plastic / Tempered Glass
TypeMicro ATX / Mini-ITX
Side Panel1 x Side Tempered Glass Panel
Front PortsUSB3.2 Gen2 Type-C*1/USB3.0*2/AUDIO*1+MIC*1(2 in 1)
BrandJonsbo
ModelD33 White
Internal 3.5" Drive Bays2
Internal 2.5" Drive Bays2
Expansion Slots4
Fan OptionsTop:120mm*3(optional); Front:120mm*2(with ATX PSU)/ 140mm*2(with SFX PSU)(optional); Rear:120mm*1(optional); Bottom:120mm*3(optional)
Radiator OptionsTop : 240mm / 360mm*1
Max GPU Length435 mm
Max CPU Cooler Height172 mm
Max PSU Length160 mm
Dimensions455(D)*238.2mm(W)*368.4mm(H) 17.91"x9.38"x14.5"
Weight6.7KG 14.77LB

이 모델의 다른 버전

같은 라인업에서 3개 더

같은 제품군에서 메모리·쿨러·클럭이 다릅니다 — 결정 전에 비교해 보세요.

이 상품에 대한 질문

Will a 435 mm graphics card fit without removing the front fans?

The case allows up to 435 mm GPU length; front fan mounts accept 120 mm fans with an ATX PSU or 140 mm fans with an SFX PSU, so card clearance depends on the PSU and fan choice.

Can I install a 360 mm radiator on the top while keeping the front fans?

Top mount supports one 360 mm radiator; front mounts remain available for 120 mm or 140 mm fans depending on PSU form factor, so both can be used together.

What motherboard sizes are compatible with the BTF layout?

The chassis fits Micro ATX, Mini-ITX and MATX BTF motherboards, giving flexibility for standard or back-plug designs.
