Four-inch IPS touchscreen with resistive layer, 800 by 480 resolution

LORDWORLD

LORDWORLD 4 inch IPS Touch Screen 800x480 Resistive

SKU CH-ZD7P-9S9N2

A 4 inch IPS resistive touch display with 800x480 resolution for direct Raspberry Pi connection via HDMI

  • 800 x 480 resolution gives sharp detail for compact projects
  • IPS panel delivers wide viewing angles with consistent colour
  • Resistive touch enables glove and stylus input for rugged use
  • Direct plug-in fits most Raspberry Pi boards without extra wiring
  • Backlight off option reduces power draw for battery operation

Product identity

The LORDWORLD 4 inch IPS touch screen delivers an 800x480 hardware resolution through a resistive panel. It connects via HDMI for video and uses GPIO pins for touch input, targeting Raspberry Pi developers and embedded-project builders who need a compact display.

Suitability and limits

The screen suits makers building portable Pi consoles, dashboard interfaces or kiosk prototypes that benefit from direct GPIO attachment. It is not for users who need a capacitive multi-touch experience, a larger viewing area, or a display that works with Pi 1 model B or Pi Zero without an extra HDMI cable.

Sustained operation

The IPS panel maintains consistent colour and contrast across wide viewing angles during long sessions. Backlight can be disabled through software to reduce power draw and heat when the interface is idle. Resistive touch remains responsive under continuous stylus or gloved-finger use without drift.

주요 특징

  • 800 x 480 resolution gives sharp detail for compact projects
  • IPS panel delivers wide viewing angles with consistent colour
  • Resistive touch enables glove and stylus input for rugged use
  • Direct plug-in fits most Raspberry Pi boards without extra wiring
  • Backlight off option reduces power draw for battery operation

사양

BrandLORDWORLD

이 상품에 대한 질문

Which Raspberry Pi models can I plug this 4 inch IPS display into directly without an HDMI cable?

Any revision of Raspberry Pi except the Pi 1 model B or Pi Zero, which need an HDMI cable for video.

Will the resistive touch panel still work if I use this screen as a regular HDMI monitor on my laptop?

No, the touch panel is unavailable in monitor mode; it only functions when the display is driven via the Raspberry Pi GPIO header.

How can I verify the backlight control is working after I install the driver on Raspbian?

Toggle the backlight using the provided driver commands; the screen should dim or turn off completely while the image remains visible.
