5.83inch e-paper HAT with 648x480 black and white screen and 40pin GPIO header

LORDWORLD

LORDWORLD 5.83inch E-Paper Display HAT 648x480

SKU CH-S9D0-FWT8D

A 5.83inch e-paper HAT with 648x480 resolution, 40-pin GPIO header and SPI interface for Raspberry Pi and Jetson Nano boards

  • Displays without backlight, retains image after power loss
  • Ultra-low power draw, energy only needed for refresh cycles
  • 40-pin GPIO header fits Raspberry Pi series and Jetson Nano
  • SPI interface connects to Raspberry, Nucleo and other controllers
  • 83 inch screen with 648 x 480 two-colour resolution

5.83 inch E-Paper HAT for Raspberry Pi

This 5.83 inch E-Paper HAT provides a 648x480 two-colour black and white display for Raspberry Pi series boards and Jetson Nano. It connects through the standard 40PIN GPIO header and an SPI interface. The module suits developers building low-power IoT edge devices or maker projects that need a persistent, readable screen without continuous power draw.

Sustained operation with ultra-low power consumption

The display requires power only during refresh cycles and retains the last image indefinitely when power is removed. No backlight is fitted, so energy use stays minimal during long deployments. This behaviour makes the board practical for battery-powered sensors, remote status panels or any application where the screen must stay visible for extended periods without a constant supply.

HAT mounting and SPI connectivity for daily use

The 40PIN GPIO extension header aligns with Raspberry Pi boards and Jetson Nano, allowing direct stacking without extra wiring. An SPI interface is also exposed for linking to other controller boards such as Nucleo. The HAT form factor keeps the display secure and the pinout accessible, simplifying integration into enclosures or prototype rigs that rely on standard Pi mounting points.

주요 특징

  • Displays without backlight, retains image after power loss
  • Ultra-low power draw, energy only needed for refresh cycles
  • 40-pin GPIO header fits Raspberry Pi series and Jetson Nano
  • SPI interface connects to Raspberry, Nucleo and other controllers
  • 83 inch screen with 648 x 480 two-colour resolution

사양

BrandLORDWORLD

이 상품에 대한 질문

Does the 5.83inch E-Paper Display HAT generate heat or draw continuous power when running all day?

The panel has no backlight and only consumes power during refresh cycles, so it stays cool and draws virtually no current while holding a static image.

Which host board must I already own to use the 40PIN GPIO extension header on this HAT?

It fits any Raspberry Pi series board or a Jetson Nano that provides the standard 40-pin GPIO header.

Will the SPI interface on this display work with an older Raspberry Pi model I already have?

Yes, the SPI connection is compatible with every Raspberry Pi series board that exposes the 40-pin GPIO header.
