Silver aluminium four-bay DAS enclosure with front cooling fan

Orico

Orico 9948C3 4-Bay USB 3.2 Gen 2 Aluminium DAS Drive Enclosure Silver

SKU CH-4C0S-NZFN8

A four-bay direct-attached aluminium enclosure with USB 3.2 Gen 2, built-in 150 W power, 80 mm fan and front-to-rear vents for up to 88 TB of SATA storage

  • Size4 Bay DAS & Type C (9948C3)
  • ColorSilver
  • External InterfaceUSB 3.2 Gen 2
  • AC AdapterYes
  • MaterialAluminum
  • FanYes

Number of Bay 4 Bay

Size 4 Bay DAS & Type C (9948C3)

  • USB 3.2 Gen 2 interface enables high-speed multi-drive data transfers
  • Four independent 3.5-inch SATA bays each support up to 22TB for massive capacity
  • Built-in 150W power supply delivers stable power across all drives simultaneously
  • Aluminium chassis with 80mm fan and vented airflow keeps temperatures low under load
  • Tool-free eject mechanism allows single-drive swaps without shutting down the enclosure

4-Bay DAS enclosure for SATA drives

The Orico 9948C3 connects four 3.5-inch SATA hard drives or SSDs to a host via USB 3.2 Gen 2 Type-C. It targets users who need direct-attached capacity without RAID complexity, supporting up to 22TB per bay for a combined 88TB. An aluminium shell and 80mm fan handle heat during sustained transfers. The unit weighs 5000g and measures 264.8mm by 137.0mm by 200.7mm.

Tool-free trays with eject buttons

Each bay uses a screw-free tray that slides in from the front and locks with a push-button release, so single-drive swaps take seconds. No driver installation is required on modern operating systems. The 150W internal power supply feeds all four drives simultaneously, preventing spin-up stalls. Auto-sleep mode spins drives down after host inactivity to reduce wear and noise.

Maximum 22TB per SATA bay

The enclosure accepts any 3.5-inch SATA HDD or SSD up to 22TB, giving a hard ceiling of 88TB across four bays. Drives larger than 22TB are not supported, so buyers planning higher single-drive capacities must choose a different platform. Daisy-chain expansion is available through the second Type-C port for additional enclosures.

주요 특징

  • USB 3.2 Gen 2 interface enables high-speed multi-drive data transfers
  • Four independent 3.5-inch SATA bays each support up to 22TB for massive capacity
  • Built-in 150W power supply delivers stable power across all drives simultaneously
  • Aluminium chassis with 80mm fan and vented airflow keeps temperatures low under load
  • Tool-free eject mechanism allows single-drive swaps without shutting down the enclosure

사양

BrandORICO
Series9948C3-US-SV-BP
Model9948C3-US-SV-BP
Size4 Bay DAS & Type C (9948C3)
ColorSilver
External InterfaceUSB 3.2 Gen 2
AC AdapterYes
MaterialAluminum
FanYes
TypeEnclosure
HDD Count SupportedWithout RAID
Number of Bay4 Bay
Maximum Capacity (per Bay)Up to 22TB
Dimensions264.8mm*137.0mm*200.7mm
Weight5000g

이 모델의 다른 버전

같은 라인업에서 4개 더

같은 제품군에서 메모리·쿨러·클럭이 다릅니다 — 결정 전에 비교해 보세요.

이 상품에 대한 질문

How do I know the enclosure is running correctly after connecting it?

The 80 mm fan spins up, the front LEDs show activity for each of the four bays, and the host recognises every inserted SATA drive without extra drivers.

What ships in the box and what must I provide?

The aluminium enclosure with built-in 150 W power supply, USB 3.2 Gen 2 Type-C cable and mounting screws are included; four 3.5-inch SATA hard drives up to 22 TB each are purchased separately.

Which capacity version should I choose for maximum storage?

The single model 9948C3-US-SV-BP supports up to 22 TB per bay for a total of 88 TB, so select drives that match your required capacity within that limit.
