Silver 21.5 inch fanless all-in-one with resistive touchscreen

partaker

Partaker A17-PA-215TPC-CE5A(J19)-8G256G1TB 21.5" all-in-one PC

SKU CH-QKSX-V208V

21.5" IP65-rated industrial all-in-one with resistive touchscreen, Intel Celeron J1900, 8GB DDR3, 256GB SSD plus 1TB HDD, fanless aluminium chassis, and Windows 10 Pro pre-installed

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeCeleron
  • CPU Name2.00GHz
  • GPU/VGA TypeIntel HD Graphics

GPU Intel HD Graphics

Memory 8GB DDR3

  • 4GB DDR3
  • 8GB DDR3

SSD 256GB

  • 64GB
  • 256GB
  • 512GB

HDD 1TB

취소선으로 표시된 버전은 존재하지만, 이곳에서는 취급하지 않습니다.

  • IP65 front-panel protection withstands dust and water jets
  • Fanless aluminium-alloy cooling runs silently with zero moving parts
  • Intel Celeron J1900 quad-core processor handles 24/7 industrial workloads
  • 5-wire resistive touchscreen rated for 35 million touches
  • Dual storage: 256 GB SSD plus 1 TB HDD for OS speed and data capacity

Industrial panel PC for embedded deployment

The Partaker A17-PA-215TPC-CE5A(J19) is a 21.5 inch all-in-one computer built around an Intel Celeron J1900 quad-core processor with 8GB DDR3L memory. It combines a 256GB mSATA SSD and a 1TB 2.5 inch SATA drive behind an IP65-rated front panel. The unit targets integrators who need a fanless Windows 10 Pro system for continuous operation in control cabinets or machinery interfaces.

Fanless aluminium cooling

Passive aluminium alloy construction eliminates moving parts and audible noise while drawing power from a 12V DC supply. The system is rated for 0 to 50°C operation with the SSD installed and 0 to 40°C when the hard drive is active. Typical brightness reaches 250 cd/m2 at a 1920 x 1080 resolution, and the backlight is specified for a minimum of 30000 hours.

Resistive touch and legacy I/O for automation

A 5-wire resistive touchscreen rated for 35 million touches enables gloved or stylus input in harsh environments. Connectivity includes VGA, one USB3.0, three USB2.0, three COM ports, LAN, audio in and out, and a Mini PCIe slot with SIM holder for wireless expansion. Embedded buckle kits support panel mounting, and the watchdog timer offers 255 levels for unattended recovery.

주요 특징

  • IP65 front-panel protection withstands dust and water jets
  • Fanless aluminium-alloy cooling runs silently with zero moving parts
  • Intel Celeron J1900 quad-core processor handles 24/7 industrial workloads
  • 5-wire resistive touchscreen rated for 35 million touches
  • Dual storage: 256 GB SSD plus 1 TB HDD for OS speed and data capacity

사양

ModelA17-PA-215TPC-CE5A(J19)-8G256G1TB
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeCeleron
CPU Name2.00GHz
GPU/VGA TypeIntel HD Graphics
Memory Capacity8GB DDR3
SSD256GB
HDD1TB
Screen Size21.5"
TouchscreenYes

이 모델의 다른 버전

같은 라인업에서 5개 더

같은 제품군에서 메모리·쿨러·클럭이 다릅니다 — 결정 전에 비교해 보세요.

이 상품에 대한 질문

How do I mount the 527.8 x 321 mm panel PC into a 522 x 315 mm cut-out using the embedded buckle kits?

Align the unit with the 522 x 315 mm opening, insert the supplied embedded buckle kits into the side slots, and tighten each buckle evenly so the front bezel sits flush and the IP65 seal is maintained.

Which storage drive will need replacement first, the 256 GB mSATA SSD or the 1 TB 2.5" SATA HDD?

The 1 TB 2.5" SATA HDD has moving parts and a lower operating-temperature ceiling of 40 °C, so it typically reaches end-of-life before the solid-state mSATA drive.

At what internal temperature does the fanless aluminium chassis throttle the Intel Celeron J1900 during continuous 24/7 operation?

The system is rated for 0–50 °C with the SSD installed; sustained loads that push the chassis beyond 50 °C will trigger thermal throttling on the J1900 processor.
