Gray 15-inch fanless industrial panel PC with IP65 touchscreen

partaker

Partaker A23 Industrial Panel PC Core i5-1135G7 8GB 128GB 15" IP65

SKU CH-G0AN-HSGE8

A 15-inch IP65-rated industrial panel PC with 10-point capacitive touch, Core i5-1135G7, 8GB DDR4, 128GB SSD, and fanless aluminium chassis for 24/7 operation

  • Form FactorAll-in-One
  • ColorGray
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i5 11th Gen
  • CPU NameIntel Core i5-1135G7
  • GPU/VGA TypeIntel Iris Xe Graphics

CPU Type Intel Core i5 11th Gen

CPU Name Intel Core i5-1135G7

GPU Intel Iris Xe Graphics

Memory 8GB DDR4

  • 16GB DDR4
  • 32GB DDR4
  • 64GB DDR4
  • 8GB DDR4

SSD 128GB

취소선으로 표시된 버전은 존재하지만, 이곳에서는 취급하지 않습니다.

  • IP65 front protection shields the 15" touchscreen from dust and water jets
  • Intel Core i5-1135G7 up to 4.20 GHz drives reliable multitasking in industrial settings
  • Fanless aluminum alloy chassis runs silently with zero moving parts to fail
  • 10-point projected capacitive touch endures 200 million touches for long-term operation
  • 12V DC input plus HDMI, VGA, 2×LAN, 2×COM, 4×USB for flexible integration

15" IP65 Industrial Panel PC

The Partaker A23 is a fanless all-in-one system built around an Intel Core i5-1135G7 processor with 8GB of DDR4 memory and a 128GB SSD. Its 15-inch TFT LED panel offers 1024x768 resolution and 10-point projected capacitive touch protected to IP65 on the front. Windows 11 Pro is pre-installed for immediate deployment in automation, HMI or kiosk roles.

Connectivity and expansion limits

The unit provides HDMI and VGA video outputs, two USB 3.0 ports, two USB 2.0 ports, dual LAN, two COM ports and audio in/out on a 12V DC input. Internal expansion uses one M.2 Key E slot for WIFI6 and one M.2 Key B slot for 5G with a SIM socket, plus a 2.5" SATA bay and an M.2 2260/2280 slot supporting PCIe x1 or SATA SSD. No other interfaces are present.

Memory ceiling decides fit

The board accepts two SODIMM DDR4-3200 modules up to a total of 64GB, so the shipping 8GB can be increased substantially for heavier workloads. Storage can also grow via the M.2 and 2.5" SATA bays. Buyers who need more than 64GB of RAM or a different memory generation must choose another platform.

주요 특징

  • IP65 front protection shields the 15" touchscreen from dust and water jets
  • Intel Core i5-1135G7 up to 4.20 GHz drives reliable multitasking in industrial settings
  • Fanless aluminum alloy chassis runs silently with zero moving parts to fail
  • 10-point projected capacitive touch endures 200 million touches for long-term operation
  • 12V DC input plus HDMI, VGA, 2×LAN, 2×COM, 4×USB for flexible integration

사양

ModelA23-I5 1135G7-8G128G
Form FactorAll-in-One
ColorGray
Operating SystemWindows 11 Pro
CPU TypeIntel Core i5 11th Gen
CPU NameIntel Core i5-1135G7
GPU/VGA TypeIntel Iris Xe Graphics
Memory Capacity8GB DDR4
SSD128GB
HDDNo
Screen Size15"
TouchscreenYes

이 모델의 다른 버전

같은 라인업에서 5개 더

같은 제품군에서 메모리·쿨러·클럭이 다릅니다 — 결정 전에 비교해 보세요.

이 상품에 대한 질문

Should I pick the 8 GB / 128 GB version or is there a larger capacity available?

This model ships with 8 GB DDR4 and a 128 GB SSD. The board accepts up to 64 GB via two SODIMM slots and has an M.2 slot plus a 2.5" bay for additional SATA storage.

What does the 4.20 GHz boost clock mean for daily industrial workloads?

The Core i5-1135G7 can reach 4.20 GHz on short bursts, letting the fanless system handle HMI, SCADA and light vision tasks without thermal throttling in 0–50 °C environments.

Which video outputs does the HDMI port actually support on this panel?

HDMI and VGA are both available; the built-in 15" screen runs at 1024 x 768 while an external display can be driven at its native resolution through HDMI.
