Silver 15 inch all-in-one industrial panel PC with resistive touchscreen

partaker

partaker A5-PA-150TPC-CE5A(I34)-8G512G 15" all-in-one PC

SKU CH-NTEQ-62BC1

A 15-inch industrial all-in-one with an IP65 front panel, high-temperature resistive touchscreen, Intel Core i3 4th Gen CPU, 8GB DDR3 RAM, 512GB SSD, and fanless aluminium housing

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i3 4th Gen
  • CPU Name1.90GHz
  • GPU/VGA TypeIntel HD Graphics 4400

GPU Intel HD Graphics 4400

Memory 8GB DDR3

  • 4GB DDR3
  • 8GB DDR3

SSD 512GB

HDD None

  • None
  • 1TB

취소선으로 표시된 버전은 존재하지만, 이곳에서는 취급하지 않습니다.

  • IP65 front panel resists dust and water ingress
  • 5-wire resistive touchscreen works at high temperatures
  • Fanless aluminium chassis runs silently in industrial settings
  • 90GHz Core i3 with 8GB DDR3 and 512GB SSD for responsive operation
  • DC 12V power with HDMI, VGA, dual LAN, USB 3.0, USB 2.0, audio and dual COM ports

Industrial 15" Panel PC

The Partaker A5-PA-150TPC-CE5A(I34) is a 15-inch all-in-one computer built for industrial environments. It integrates an Intel Core i3 4th Gen processor at 1.90GHz with 8GB DDR3L memory and a 512GB SSD. The unit ships with Windows 10 Pro installed and features a high-temperature five-wire resistive touchscreen protected to IP65 on the front panel. Its fanless aluminium chassis supports embedded, wall, desktop or cantilever mounting.

Sustained Load Behaviour

The fanless cooling system relies on the aluminium alloy housing to dissipate heat without moving parts. Operating temperature is rated 0 to 50°C with the installed SSD, dropping to 0 to 40°C if a mechanical drive is used. The Intel HD Graphics 4400 and DDR3L 1333/1600 memory deliver steady performance for typical HMI, SCADA or edge-gateway workloads. A hardware watchdog timer with 255 steps provides automatic recovery if the system hangs during long-running operation.

Deciding Specification

The five-wire resistive touchscreen works with gloves or stylus and is rated for 200 million touches, making it the key feature for dirty or gloved environments. Display resolution is fixed at 1024 x 768 with 350 cd/m² brightness and 86±5% transmittance. Connectivity includes HDMI, VGA, dual LAN, two COM ports, two USB 3.0, two USB 2.0 and audio I/O. Expansion is via a full-size Mini PCIe slot with SIM holder. Power input accepts 12V DC from a 100-240V AC adapter.

주요 특징

  • IP65 front panel resists dust and water ingress
  • 5-wire resistive touchscreen works at high temperatures
  • Fanless aluminium chassis runs silently in industrial settings
  • 90GHz Core i3 with 8GB DDR3 and 512GB SSD for responsive operation
  • DC 12V power with HDMI, VGA, dual LAN, USB 3.0, USB 2.0, audio and dual COM ports

사양

ModelA5-PA-150TPC-CE5A(I34)-8G512G
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeIntel Core i3 4th Gen
CPU Name1.90GHz
GPU/VGA TypeIntel HD Graphics 4400
Memory Capacity8GB DDR3
SSD512GB
HDDNo
Screen Size15"
TouchscreenYes

이 모델의 다른 버전

같은 라인업에서 5개 더

같은 제품군에서 메모리·쿨러·클럭이 다릅니다 — 결정 전에 비교해 보세요.

이 상품에 대한 질문

How does the fanless aluminium housing manage heat during continuous 24-hour operation?

The aluminium-alloy chassis acts as a passive heatsink, rated for 0–50 °C ambient with the installed SSD and 0–40 °C if a 2.5″ SATA drive is added.

Which display cables do I need to connect a second monitor to the HDMI or VGA ports?

The unit provides one HDMI and one VGA output; a standard HDMI cable or VGA cable is required for each external screen you attach.

Will the 1024 × 768 resistive touchscreen still register input when I wear light industrial gloves?

The five-wire resistive layer responds to pressure, so gloved or stylus input works without calibration changes.
