15.6 inch industrial all-in-one PC with IP65 resistive touchscreen and fanless aluminium chassis

partaker

partaker A7 all-in-one PC 15.6" i7-6500U 16GB DDR3 256GB SSD

SKU CH-RXXN-4N45K

A 15.6" industrial all-in-one PC with IP65 front protection, resistive touchscreen, Intel i7-6500U, 16GB DDR3 and 256GB SSD, ready for 24/7 operation

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 6th Gen
  • GPU/VGA TypeIntel HD Graphics 520
  • Memory Capacity16GB DDR3
  • SSD256GB

Memory Capacity 16GB DDR3

  • IP65 front panel resists dust and water jets
  • i7-6500U up to 3.10 GHz powers 7x24 operation
  • Fanless aluminium alloy chassis runs silent
  • 6" 1920 x 1080 resistive touch rated 35 million touches
  • Windows 11 Pro pre-installed for immediate deployment

Industrial Panel PC

The Partaker A7 is a 15.6 inch all-in-one computer built around an Intel Core i7-6500U processor with Intel HD Graphics 520. It ships with 16GB of DDR3 memory and a 256GB SSD, running Windows 11 Pro on a TFT LED display with a high-temperature five-wire resistive touchscreen. The front panel carries IP65 protection and the aluminium alloy chassis uses fanless passive cooling for silent 7x24 operation.

Suited for fixed industrial installations

This unit fits embedded, wall-mounted, desktop or cantilevered mounting with a 386.5 by 236 millimetre cut-out and operates from 0 to 50 degrees Celsius with the SSD installed. It provides HDMI, VGA, two USB 3.0, two USB 2.0, dual LAN, audio in and out, and two COM ports plus a mini PCIe slot with SIM slot for expansion. Buyers who need a capacitive touchscreen, a battery-powered mobile device or a higher brightness panel should look at other form factors.

Resistive touchscreen with IP65 front protection

The five-wire resistive screen delivers 35 million touch cycles and 80 percent transmittance at 550 nanometre wavelength, allowing reliable input with gloves or stylus in dusty or wet environments. Combined with the sealed front bezel this makes the panel suitable for factory floors, kiosks and outdoor cabinets where moisture or particulates would defeat a standard consumer display.

주요 특징

  • IP65 front panel resists dust and water jets
  • i7-6500U up to 3.10 GHz powers 7x24 operation
  • Fanless aluminium alloy chassis runs silent
  • 6" 1920 x 1080 resistive touch rated 35 million touches
  • Windows 11 Pro pre-installed for immediate deployment

사양

ModelA7-PA-156TPC-CE5A(I76))-16G256G
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 6th Gen
GPU/VGA TypeIntel HD Graphics 520
Memory Capacity16GB DDR3
SSD256GB
HDDNo
Screen Size15.6"
TouchscreenYes

이 모델의 다른 버전

같은 라인업에서 5개 더

같은 제품군에서 메모리·쿨러·클럭이 다릅니다 — 결정 전에 비교해 보세요.

이 상품에 대한 질문

What panel cut-out dimensions are needed for the embedded mounting buckles?

The opening hole measures 386.5 mm by 236 mm for flush panel installation.

Which screwdriver step is often missed when fitting the mSATA or M.2 2280 drive inside the sealed chassis?

Remove the rear cover screws, insert the drive at an angle into the slot, then secure it with the retention screw before resealing the IP65 gasket.

Which component has a rated backlight life of 30,000 hours and may need replacement after continuous 24/7 use?

The 15.6" TFT LED panel backlight is rated for a minimum of 30,000 hours.
