Phanteks
Phanteks PH-F120MP_WT02 120mm PWM case fan, white, 2200 RPM
120 mm PWM fan with UFB bearing, 500–2200 RPM, 60.5 CFM airflow and 34.2 dBA noise, built for high static pressure on radiators and heatsinks
- TypeCase Fan
- CompatibilityCase
- Bearing TypeUFB (Updraft Floating Balance) Bearing
- RPM500 - 2200 +/- 10% RPM
- Air Flow60.5 CFM
- Noise Level34.2 dBA
- High static pressure for dense radiators and heatsinks
- Aerodynamically optimised blades cut turbulence for 34.2 dBA quiet running
- UFB bearing and PBT frame extend operating life
- Daisy-chain cables with 500 mm extension simplify multi-fan wiring
- 500–2200 RPM PWM range delivers 60.5 CFM when needed
Phanteks 120mm MP PWM Fan
This 120mm PWM case fan is built for high static pressure on radiators, heatsinks and dense dust filters. The UFB bearing and aerodynamically shaped blades target quiet operation across a 500 to 2200 RPM range. White frame and blades suit colour-coordinated builds. It suits users who prioritise cooling density over raw airflow volume.
Fits standard 120mm mounting points
The 4-pin PWM connector allows motherboard speed control, while the included 500mm extension cable enables daisy-chaining multiple fans to a single header. Rubber mounting pads decouple vibration from the case. Four screws are supplied. No additional controller or hub is required for basic operation.
Bundle adds daisy-chain cable
The 500mm extension cable lets several fans share one motherboard header, reducing cable clutter. Rubber sound-dampening pads on the mounting holes absorb motor vibration that would otherwise transmit to the chassis. These accessories directly lower audible noise and simplify multi-fan wiring without extra parts.
주요 특징
- High static pressure for dense radiators and heatsinks
- Aerodynamically optimised blades cut turbulence for 34.2 dBA quiet running
- UFB bearing and PBT frame extend operating life
- Daisy-chain cables with 500 mm extension simplify multi-fan wiring
- 500–2200 RPM PWM range delivers 60.5 CFM when needed
사양
| Brand | Phanteks |
|---|---|
| Series | 120mm MP PWM Fan |
| Model | PH-F120MP_WT02 |
| Type | Case Fan |
| Compatibility | Case |
| Bearing Type | UFB (Updraft Floating Balance) Bearing |
| RPM | 500 - 2200 +/- 10% RPM |
| Air Flow | 60.5 CFM |
| Noise Level | 34.2 dBA |
| Power Connector | 4-Pin PWM |
| Color | Frame: White, Blades: White |
| Features | High static pressure fan designed to deliver the best performance on radiators and heatsinks. Smooth fan blades are aerodynamically optimized for silent operation. Wide RPM range up to 2200 rpm for the highest performance when needed. Premium and solid construction using PBT material and UFB (Updraft Floating Balance) bearing. Available in 3 different colors; all black, all white or black frame with white blades. |
| Dimensions | 120 x 120 x 25 mm |
| Package Contents | 1x PH-F120MP_WT02 Premium Fan 1x 500mm 4 pin extension cable 4x Fan Screws |
| 배송 무게 | 0.25 kg |
| 포장 크기 | 203 × 193 × 28 mm |
이 상품에 대한 질문
How fast can the Phanteks PH-F120MP_WT02 spin before its PWM curve hits the ceiling?
The fan tops out at 2200 RPM with a 10 percent tolerance, so the motherboard can drive it up to that speed under sustained load.
What noise and heat output should I expect if the fan runs at maximum speed all day?
At 2200 RPM the fan produces 34.2 dBA and draws power only through the 4-pin PWM connector, with no separate heat figure provided.
Which motherboard header or controller do I need to run this 4-pin PWM fan?
A standard 4-pin PWM fan header on the motherboard or a compatible fan hub is required; a 500 mm extension cable is included for daisy-chaining.
