Flat ribbon cable of forty 6-inch male-to-male jumper wires in ten colours

Adafruit

Adafruit Premium Male/Male Jumper Wires 40 x 6

SKU CH-GEHA-J8HNX

Forty 6-inch male-to-male jumper wires in ten colours on a 0.1-inch pitch ribbon cable for breadboard prototyping

  • TypePrototyping Products
  • 40 wires in ten colours simplify colour-coded prototyping
  • 6-inch length suits compact breadboard layouts
  • 1-inch male headers fit standard 2.54 mm pitch
  • 28 AWG stranded conductors stay flexible for repeated use
  • Ribbon cable keeps wires organised or peels apart for custom harnesses

Premium Male/Male Jumper Wires

This pack contains 40 individual wires, each 6 inches (150 mm) long, arranged as a 0.1 inch (2.54 mm) pitch ribbon cable. The set provides four pieces in each of ten distinct colours for easy circuit identification. They are designed for prototyping on standard headers and breadboards.

28 AWG Stranded Ribbon Construction

Each conductor uses 28 AWG gauge wire built from 7 strands of 36 AWG for flexibility and durability. The ribbon format keeps wires organised; users can peel off single strands or keep groups intact for tidy harnesses. Silver latch contacts fit cleanly side by side on 0.1 inch headers without crowding adjacent pins.

Fixed Length and Pin Spacing

The 6 inch length and 0.1 inch pitch suit typical bench prototyping but limit reach inside larger enclosures or across widely spaced boards. Builders needing longer jumpers, different gauges, or female terminations must source separate products. The ribbon layout also prevents arbitrary wire routing once separated.

Najważniejsze cechy

  • 40 wires in ten colours simplify colour-coded prototyping
  • 6-inch length suits compact breadboard layouts
  • 1-inch male headers fit standard 2.54 mm pitch
  • 28 AWG stranded conductors stay flexible for repeated use
  • Ribbon cable keeps wires organised or peels apart for custom harnesses

Specyfikacja

TypePrototyping Products

Pytania dotyczące tego produktu

What pitch do the male header contacts match on a PCB?

The contacts are sized for standard 0.1 inch or 2.54 mm pitch headers.

How many individual wires are in the ribbon strip?

The strip contains 40 wires, arranged as four pieces in each of ten colors.

Which side of the connector should face out when plugging several in a row?

Orient the silver latch tab outward because that side is slightly wider than the 0.1 inch pitch.
