Compact tall mini-PC barebone in dark finish with front ports visible

ASUS

ASUS NUC 12 Pro Wall Street Canyon i5-1240P Tall Barebone

SKU CH-B1ZP-SPWKP

A compact barebone mini PC with a 12-core Intel Core i5-1240P, dual-channel DDR4-3200 support up to 64 GB, two M.2 slots for NVMe and SATA SSDs, dual Thunderbolt 4 ports, dual HDMI 2.0b.

  • CPU Type12th Gen Intel® Core™ i5-1240P
  • Memory installedNo Memory
  • Memory slot2 x 260Pin SO-DIMM
  • Memory Type SupportedDDR4 3200
  • Max Memory Supported64GB
  • Dual Channel Memory SupportedYes
  • 12-core i5-1240P with Iris Xe handles multi-threaded workloads
  • Dual-channel DDR4-3200 supports up to 64GB memory
  • M.2 2280 PCIe Gen4 plus M.2 2242 PCIe Gen3 for fast storage
  • Two Thunderbolt 4 and two HDMI 2.0b drive multiple 4K displays
  • Intel 2.5Gb LAN and Wi-Fi 6E AX211 give high-speed wired and wireless connectivity

ASUS NUC 12 Pro i5-1240P Tall Barebone

This mini PC barebone ships with a 12th Gen Intel Core i5-1240P processor featuring 12 cores and 16 threads. Integrated Iris Xe graphics handle display output. The unit requires user-supplied DDR4-3200 SO-DIMMs and M.2 storage to become a working system. A 120W 19V power supply is included in the box.

Professionals needing compact 24/7 compute

The barebone suits IT managers deploying digital signage, kiosks or office endpoints that run continuously. Dual-channel memory support and two Thunderbolt 4 ports simplify multi-display workflows. Builders who want pre-installed RAM or a larger 2.5-inch drive bay should look at a different chassis.

Single M.2 2280 PCIe Gen 4 NVMe slot

The primary storage socket accepts one 2280 drive running at PCIe x4 Gen 4 speeds up to 8TB capacity. A secondary 2242 socket supports PCIe x1 Gen 3 or SATA devices. Buyers needing two full-speed Gen 4 NVMe drives cannot use this platform.

Najważniejsze cechy

  • 12-core i5-1240P with Iris Xe handles multi-threaded workloads
  • Dual-channel DDR4-3200 supports up to 64GB memory
  • M.2 2280 PCIe Gen4 plus M.2 2242 PCIe Gen3 for fast storage
  • Two Thunderbolt 4 and two HDMI 2.0b drive multiple 4K displays
  • Intel 2.5Gb LAN and Wi-Fi 6E AX211 give high-speed wired and wireless connectivity

Specyfikacja

BrandASUS
CPU Type12th Gen Intel® Core™ i5-1240P
Memory installedNo Memory
Memory slot2 x 260Pin SO-DIMM
Memory Type SupportedDDR4 3200
Max Memory Supported64GB
Dual Channel Memory SupportedYes
M.2 Slot1x M.2 22x80 socket supporting PCIe x4 Gen 4 NVMe from 128GB to 8TB or SATA SSD from 128GB to 2TB
1x M.2 22x42 socket (non-dual-LAN only) supporting PCIe x1 Gen3 NVMe from 128GB to 512GB or SATA SSD from 128GB to 512GB
Integrated GraphicsIntel® Iris® Xe Graphics
Channel7.1 multichannel digital audio via HDMI & Thunderbolt
LAN1x Intel® 2.5Gb LAN
Wireless LANIntel Wi-Fi 6E AX211, 802.11ax
Front USB2x Front USB 3.2 Gen2 type-A
Front Audio Ports3.5mm front stereo headset jack
HDMI2x HDMI 2.0b
Thunderbolt 32x Thunderbolt 4 (Alt-DP)
Rear USB1x Rear USB 3.2 Gen2 type-A
1x Rear USB 2.0 type-A
RJ451
Input12-20VDC variable DC input
Power Supply120W 19V PSU supplied
Dimensions117x112x54mm
FeaturesPrimary storage up to 8TB Gen4
NVMe or 2TB SATA SSD
Secondary storage up to 512GB Gen
3 PCIe or 512GB SATA (non-dual-LAN
only)
Tertiary 2.5” drive up to 8TB SATA
Memory up to 64GB
Replaceable lid for I/O expansion
Rear panel expansion (dual-LAN)

Pytania dotyczące tego produktu

What memory modules will I need to add later and how much can the system take?

The board has two 260-pin SO-DIMM slots for DDR4-3200 running at 1.2 V; it supports up to 64 GB in dual-channel mode.

Which component hits its ceiling first when the i5-1240P runs at full load for long periods?

The processor is rated at 35 W TDP with P-cores up to 4.4 GHz and E-cores up to 3.3 GHz; sustained turbo will be limited by the cooling solution and the 120 W 19 V power adapter.

How loud and hot does the unit get when it runs 24/7?

The chassis is qualified for 24/7 operation with the supplied 120 W 19 V PSU; actual fan noise and surface temperature depend on the installed SSD and memory configuration.
