Green circuit board with metal bracket, five rear ports: two USB-C and three USB-A

ESTONE

ESTONE PCIE23A2C 5-Port PCIe USB 3.0 Expansion Card (2 USB-C, 3 USB-A)

SKU CH-PR98-D1RFV

Adds five USB 3.0 ports — two Type-C and three Type-A — to a desktop via a PCI Express x1 slot, delivering up to 5 Gbps total bandwidth

  • TypePCI to USB Card
  • External USB Ports5x USB Ports
  • StandardUSB 3.0
  • Data Transfer RateUp to 5.0 Gbps
  • Operating Systems SupportedWindows 7/8/10/11
  • CompatibilityWidely Compatibility: The card is compatible with Windows 7/
  • Add five USB ports with a single PCIe x1 card
  • Two USB-C and three USB-A connectors for modern and legacy devices
  • Up to 5.0 Gbps transfer speed for large file moves
  • Works with Windows 7 through 11 and Mac OS 10.8.2 or later
  • No external power cable needed; draws up to 12 A from the slot

Five USB 3.0 ports on a single x1 slot

This ESTONE PCIE23A2C card adds two USB-C and three USB-A connectors to a desktop through any PCI Express x1, x4, x8 or x16 socket. The host controller delivers a shared 5 Gbps ceiling across all ports and is backward compatible with USB 2.0 and 1.1 devices. Driver installation is required for Windows 7, 8, Vista, XP and Server 2008, while Windows 10, 11 and Mac OS 10.8.2 or later work without extra software. No external power adapter is needed; the card draws 5 V / 12 A from the slot.

Builders adding multiple peripherals to an older

The five-port layout suits users who need several high-current devices such as external drive enclosures or VR sensors at once, with each port capable of 5 V / 3 A. It will not serve anyone who requires Power Delivery fast charging, BC 1.2 charging negotiation, or video output over USB-C because the card handles data only. Buyers needing Thunderbolt protocol support or an external power connector for even higher loads should look elsewhere.

Steady 5 Gbps throughput with distributed current

Under sustained load the shared 5 Gbps bandwidth divides among active ports, so copying large media libraries to multiple drives runs at the aggregate limit rather than per-port peaks. Four onboard power modules keep the 12 A total current stable during long transfers, preventing brown-outs on power-hungry enclosures. The FRE100 controller maintains consistent signalling without thermal throttling in typical chassis airflow.

Najważniejsze cechy

  • Add five USB ports with a single PCIe x1 card
  • Two USB-C and three USB-A connectors for modern and legacy devices
  • Up to 5.0 Gbps transfer speed for large file moves
  • Works with Windows 7 through 11 and Mac OS 10.8.2 or later
  • No external power cable needed; draws up to 12 A from the slot

Specyfikacja

BrandESTONE
SeriesPCIE23A2C
ModelPCIE23A2C
TypePCI to USB Card
External USB Ports5x USB Ports
StandardUSB 3.0
Data Transfer RateUp to 5.0 Gbps
Operating Systems SupportedWindows 7/8/10/11
CompatibilityWidely Compatibility: The card is compatible with Windows 7/8/10/11 (32/64 bit) and Mac OS 10.8.2 and above. The card only requires installing a driver which you can download from our CD driver, when operating on Windows 7. Note: Windows XP,/Vista/7, Server,requires driver installation, Windows 10/11 and Mac OS and Linux don't need drivers.
Specifications5 Ports PCI-E to USB 3.0 HUB PCI Express Expansion Card Adapter 5Gbps for Motherboard
You need to install the RENESAS/VLI USB3.0 driver for your computer first.
Supports PCI Express 2.0 X1 lane, can transferring up to 5Gbps.
PCI Express x1 slot card for usb expansion 7 Ports USB interface Card (2X USB-C - 5X USB-A)
Power Input: no need extral Power Connector
Power output: +/-5V / 900mA (each port)
Compatible: USB1.1/2.0/3.0
Operating Systems: Windows7/8/10(32/64bit)
?
FeaturesPCI Express x1 slot card for usb expansion 5 Ports USB interface Card (2X USB-C - 3X USB-A)
USB3.0 Backwards compatible older USB 2.0 and 1.1 devices; Comply with PCI-e 3.0 PCIe 2.0 motherboards, Fits PCI Express x1, x4, x8 or x16 socket .Operating System Supports Windows XP/Vista/2008 Server/7/8/10,and Mac 0s (10.8.2 above) . Note: Windows XP,/Vista/7, Server,requires driver installation, Windows 10 and Mac OS 10.8.2 above don't need drivers.
transfer rates of up to 5Gbps copying HD videos, music, photos,data files between USB devices and the computer at blazing fast speeds.Note:The
Dimensions4.92 x 4.06 x 1.06 inches
Weight3.2 ounces
Package Contents1x USB 3.0 PCI-E expansion card, 1x CD driver, 1 x installation screws, and 1x user manual.

Pytania dotyczące tego produktu

Does my desktop need a free PCI Express x1, x4, x8 or x16 slot for this card?

Yes, the card fits any PCI Express x1, x4, x8 or x16 socket on the motherboard.

Will my existing USB 2.0 and 1.1 devices work at their normal speeds when plugged into the new ports?

The card is backwards compatible, so older USB 2.0 and 1.1 devices operate at their rated speeds.

How can I verify the card is delivering up to 5 Gbps per port after installation?

Transfer a large file to a USB 3.0 storage device and check that the sustained read or write speed approaches the 5 Gbps limit.
