Small green circuit board with a silver M12 lens and 15cm flat ribbon cable attached

KEHIPI

KEHIPI Raspberry Pi Camera Module 3 Wide 120° IMX708 Manual Focus M12 Lens 15cm 15-22 Pin Cable

SKU CH-5W0X-PSEK0

A 12-megapixel IMX708 camera module with a 120° M12 manual-focus lens and a 15 cm 15-22 pin cable for Raspberry Pi boards

  • 12 MP IMX708 sensor captures detailed stills and Full HD video
  • 120° wide-angle M12 lens expands field of view for broader scenes
  • Manual focus M12 mount enables precise close-up and low-light control
  • 15 cm 15-22 pin FFC cable connects directly to Raspberry Pi CSI port
  • Native libcamera and Picamera2 support simplifies software integration

Wide-Angle Camera Module for Raspberry Pi

The KEHIPI Camera Module 3 Wide uses a 12-megapixel IMX708 sensor with a 120-degree horizontal field of view. It connects to any Raspberry Pi board via a 15cm 15-22 pin FFC cable and supports libcamera and Picamera2 libraries. Manual focus is adjusted through the M12 lens mount for precise control.

Makers needing wide coverage and manual focus

This module suits projects that require a broad viewing angle and fixed focus settings such as surveillance, robotics or macro photography. It is not for users who need autofocus convenience or a standard field of view for general-purpose snapshots.

12 MP sensor with HDR headroom

The IMX708 captures stills at 4608 by 2592 pixels and can output up to 3 megapixels in HDR mode. The wide M12 lens maintains depth of field across the scene, while the 15cm cable limits placement distance from the board.

Najważniejsze cechy

  • 12 MP IMX708 sensor captures detailed stills and Full HD video
  • 120° wide-angle M12 lens expands field of view for broader scenes
  • Manual focus M12 mount enables precise close-up and low-light control
  • 15 cm 15-22 pin FFC cable connects directly to Raspberry Pi CSI port
  • Native libcamera and Picamera2 support simplifies software integration

Specyfikacja

BrandArducam
ModelIMX708

Pytania dotyczące tego produktu

Which Raspberry Pi boards accept the 15 cm 15-22 pin cable included with this camera?

The cable connects to any Raspberry Pi board with a 22-pin CSI connector, including Pi 5, Pi 4B, Pi 3B and Pi Zero W/2 W.

Will the 120° M12 lens cover the full 11.9 MP IMX708 sensor on my existing Pi 4B?

Yes, the wide-angle lens projects across the entire sensor, giving 4608 × 2592 stills and full-sensor video on Pi 4B.

How can I confirm HDR mode is active at 3 megapixels after installing libcamera?

Run libcamera-still with the HDR flag; the resulting JPEG will be 3 MP and the metadata will show HDR enabled.
