Green PCB with ten black SATA ports and a gold PCIe x1 edge connector

RIITOP

RIITOP PCIE2SATA-10P 10 Port SATA Expansion Card

SKU CH-JF58-GTJJP

Adds ten SATA 3.0 ports through a PCIe x1 slot with included cables and a low-profile bracket

  • TypeController Card
  • Internal Ports10x SATA 3.0
  • StandardPCIe to SATA Expansion Card 10 Port
  • Operating Systems SupportedFor Windows 7, 8.x, 10, For Windows Server 2008 R2, 2012, 20
  • Cache Size/SpeedSATA 3.0 6Gbps
  • CompatibilityPCI-e 1x / 4x / 8x / 16x
  • Add 10 SATA 3.0 ports through a single PCIe x1 slot
  • Achieve 6 Gbps transfer rates with SATA 3.0 compliance
  • Works with Windows, Linux and NAS systems without extra drivers
  • Supports 2.5" SSDs, 3.5" HDDs and 5.25" optical drives
  • Includes low-profile bracket and 10 SATA cables for compact builds

What it adds

The RIITOP PCIE2SATA-10P is a PCIe to SATA expansion card that adds ten SATA 3.0 ports through a single x1 slot. It uses the JMB575 plus ASM1166 chipset and supports 6 Gbps transfer rates with backward compatibility to 1.5 and 3.0 Gbps. Ten SATA cables and a low-profile bracket are included in the box.

Who it suits and who it does not

Builders who need many extra SATA connections for 2.5-inch SSDs, 3.5-inch HDDs or 5.25-inch optical drives will find the ten ports convenient. The card works with Windows 7 through 10, Windows Server 2008 R2 to 2019 and Linux kernels 2.6 to 4.x. It is not for systems that lack a free PCIe x1 or larger slot, nor for users who want to boot the operating system from a drive attached to this controller.

Deciding specification

The single specification that decides fit is the ten internal SATA 3.0 ports delivered over a PCIe x1 interface. If the build requires that many simultaneous SATA devices and the motherboard has an available x1, x4, x8 or x16 slot, the card matches the requirement.

Najważniejsze cechy

  • Add 10 SATA 3.0 ports through a single PCIe x1 slot
  • Achieve 6 Gbps transfer rates with SATA 3.0 compliance
  • Works with Windows, Linux and NAS systems without extra drivers
  • Supports 2.5" SSDs, 3.5" HDDs and 5.25" optical drives
  • Includes low-profile bracket and 10 SATA cables for compact builds

Specyfikacja

BrandRIITOP
ModelPCIE2SATA-10P
TypeController Card
Internal Ports10x SATA 3.0
StandardPCIe to SATA Expansion Card 10 Port
Operating Systems SupportedFor Windows 7, 8.x, 10, For Windows Server 2008 R2, 2012, 2016,2019, For Linux 2.6.x to 4.x.
Cache Size/SpeedSATA 3.0 6Gbps
CompatibilityPCI-e 1x / 4x / 8x / 16x
SpecificationsChipset: JMB575 + ASM1166. Slot: Suiltable for PCI Express 1x (or above). Port Number: 10 Port SATA 3.0. Dimension: 80*22 mm.
Features10 Ports AHCI SATA III (6 Gbps) through PCI Express x1 Slot. Fully compliant with SATA 3.0 specifications and backward compatible with SATA I/II (1.5/3.0Gbps). Compliant with PCI Express 3.0 standards. JMB575 + ASM1166 Chipset. Includes Low Profile/Half-Height installation bracket.
Package Contents1x RIITOP PCIe x1 SATA iii Expansion Card 10Ports; 10x SATA Cables; 1x Low-Profile Bracket.

Pytania dotyczące tego produktu

What cables and brackets come with the RIITOP PCIE2SATA-10P?

The box contains the 10-port expansion card, ten SATA cables and a low-profile bracket for slim cases.

Which PCIe slot version should I use for full 6 Gbps speed on all ten ports?

Install the card in a PCIe 3.0 or 4.0 x1 (or larger) slot; the JMB575+ASM1166 chipset runs at Gen3 x1 bandwidth.

Will a SATA 3.0 SSD actually reach 6 Gbps through the x1 link?

Each port supports SATA 3.0 6 Gbps; the PCIe 3.0 x1 upstream provides enough bandwidth for multiple drives at near-full speed.
