Silver 3.5-inch hard drive with silver label showing WD Red Plus 14TB branding

Western Digital

Western Digital WD140EFGX 14TB 3.5" 7200 RPM 512MB Cache SATA internal hard drive

SKU CH-X2XT-6PE74 MPN WD140EFGX

14 TB CMR drive for up to 8-bay NAS with 7200 RPM, 512 MB cache and 180 TB/yr workload rating

  • InterfaceSATA 6.0Gb/s
  • Capacity14TB
  • NAND Flash Memory TypeHard Drives
  • Recording TechnologyCMR
  • RPM7200 RPM
  • Cache512MB

Options 14TB

  • 14TB
  • 10TB

Preškrtnuté verzie existujú, ale nie sú tu skladom.

  • Designed for up to 8-bay NAS systems
  • 180 TB/yr workload rate for heavy use
  • 7200 RPM with 512MB cache for responsive access
  • CMR recording technology for reliable data storage
  • NASware 3.0 firmware boosts compatibility

14TB NAS drive for multi-bay arrays

The WD Red Plus WD140EFGX is a 14TB 3.5-inch hard drive built for small- to medium-business NAS enclosures. It uses conventional magnetic recording and spins at 7200 RPM with a 512MB cache to sustain heavy multi-user workloads. The drive is rated for up to 180 TB per year and supports systems with up to eight bays.

SATA 6.0Gb/s interface fits standard NAS bays

The drive connects through a SATA 6.0Gb/s port and conforms to the 3.5-inch form factor measuring 147.00mm long, 101.60mm wide and 26.10mm high. It requires a NAS chassis with an available 3.5-inch bay and a SATA data plus power cable. NASware 3.0 firmware handles RAID array rebuilding and improves compatibility with common NAS operating systems.

24x7 operation with managed thermals and power

Designed for continuous 24x7 environments, the drive balances heat output and acoustic profile for rack-mounted or desktop NAS units. Power draw scales with the 7200 RPM spindle speed during sustained reads, writes and RAID reconstruction. The 3-year limited warranty covers operation within the specified workload and temperature limits.

Prednosti

  • Designed for up to 8-bay NAS systems
  • 180 TB/yr workload rate for heavy use
  • 7200 RPM with 512MB cache for responsive access
  • CMR recording technology for reliable data storage
  • NASware 3.0 firmware boosts compatibility

Špecifikácie

BrandWD
SeriesRed Plus
ModelWD140EFGX
InterfaceSATA 6.0Gb/s
Capacity14TB
NAND Flash Memory TypeHard Drives
Recording TechnologyCMR
RPM7200 RPM
Cache512MB
FeaturesTackle Intensity with WD Red Plus
Packed with power to handle the small- to medium-sized business NAS environments and increased workloads for SOHO customers, WD Red Plus is ideal for archiving and sharing, as well as RAID array rebuilding on systems using ZFS and other file systems. Built and tested for up to 8-bay NAS systems, these drives give you the flexibility, versatility, and confidence in storing and sharing your precious home and work files.
For Small or Medium Businesses
Stream, backup, share, and organize your digital content with a NAS and WD Red Plus drives designed to
UsageFor NAS systems
Form Factor3.5"
Height (maximum)26.10mm
Width (maximum)101.60mm
Length (maximum)147.00mm
Prepravná hmotnosť0.82 kg
Rozmery balenia229 × 152 × 76 mm

Ďalšie verzie tohto modelu

Ďalších 1 v tomto rade

Rovnaký rad, iná pamäť, chladič alebo frekvencia — porovnajte pred rozhodnutím.

Otázky k tomuto produktu

How many terabytes per year can the WD140EFGX sustain in a 24×7 NAS workload?

The drive is rated for up to 180 TB/yr workload rate, which is the limit you will hit first under sustained write-heavy use in a multi-bay NAS.

What noise and heat levels should I expect from the WD140EFGX running continuously in an 8-bay enclosure?

At 7200 RPM the WD140EFGX produces typical 3.5-inch drive acoustics and heat; adequate case airflow is needed to keep temperatures within spec during all-day operation.

Which host interface and firmware does the WD140EFGX require to work in my NAS?

It needs a SATA 6.0Gb/s port and benefits from NASware 3.0 firmware for compatibility with up to 8-bay NAS systems.
