GIGABYTE
GIGABYTE GC-4XM2G4 PCIe 4.0 M.2 expansion card
Adds four PCIe 4.0 M.2 slots with copper heatsink and fan cooling, plus one-click RAID 0, 1 and 10 via included software
- TypePCI Express to M.2 Card
- External PortsExtended to 4 x M.2 Internal Connectors (Socket 3, M Key, Ty
- Internal PortsPCI Express x16, Compatible with PCI Express x16 and x8 Slot
- StandardPCIe 4.0
- CompatibilityPCI Express x16 M.2 (Socket 3, M key, type 2242/2260/2280/22
- SpecificationsLED: 4 x M.2 activity LEDs
- Add four PCIe 4.0 SSDs via a single x16 slot
- Full PCIe 4.0 bandwidth on every M.2 connector
- 5 mm copper heatsink with dual-ball fan cools both SSD sides
- One-click RAID 0, 1 or 10 setup in AORUS Storage Manager
- Choose three fan profiles to match thermal needs
Four M.2 slots on PCIe 4.0
The GIGYBYTE GC-4XM2G4 is a PCIe 4.0 x16 add-in card that adds four M-key M.2 slots for 2242, 2260, 2280 and 22110 SSDs. It includes a copper heatsink, thermal pads and a 5 cm double-ball bearing fan to cool both sides of installed drives. AORUS Storage Manager software enables RAID 0, 1 and 10 with a single click.
Fits x16 or x8 slots with a catch
Install the card in a PCIe x16 slot to use all four M.2 connectors at full speed. In a PCIe x8 slot only the first two M.2 slots function, so builders with limited lane availability lose half the capacity. The card requires active cooling clearance for the onboard fan and heatsink assembly.
PCIe 4.0 x16 host interface decides throughput
The card connects through a PCIe 4.0 x16 edge connector, delivering up to 15000 MB/s aggregate bandwidth with four Gen4 SSDs in RAID 0. If the motherboard supplies only PCIe 3.0 x16 or x8 electrical links, maximum throughput drops proportionally and RAID performance scales down.
จุดเด่น
- Add four PCIe 4.0 SSDs via a single x16 slot
- Full PCIe 4.0 bandwidth on every M.2 connector
- 5 mm copper heatsink with dual-ball fan cools both SSD sides
- One-click RAID 0, 1 or 10 setup in AORUS Storage Manager
- Choose three fan profiles to match thermal needs
ข้อมูลจำเพาะ
| Brand | GIGABYTE |
|---|---|
| Series | AORUS Gen4 AIC Adaptor |
| Model | GC-4XM2G4 |
| Type | PCI Express to M.2 Card |
| External Ports | Extended to 4 x M.2 Internal Connectors (Socket 3, M Key, Type 2242/2260/2280/22110 PCIe x4 SSD Support) Support for RAID 0, RAID 1, and RAID 10* * Supported RAID levels vary by platform. |
| Internal Ports | PCI Express x16, Compatible with PCI Express x16 and x8 Slots (If the adpater card is installed in a x8 slot, only the M2_1 and M2_2 connectors can be used.) |
| Standard | PCIe 4.0 |
| Compatibility | PCI Express x16 M.2 (Socket 3, M key, type 2242/2260/2280/22110 PCIe x4 SSD support) |
| Specifications | LED: 4 x M.2 activity LEDs |
| Features | 4 x PCIe 4.0/3.0 M.2 Slots Full PCI Express 4.0 Ready Design Advanced Thermal Solution for PCIe 4.0 SSD Easy Software RAID with Single Click for Amazing Performance Custom AORUS Storage Manager |
| Dimensions | 10.31" x 4.53" |
| น้ำหนักในการจัดส่ง | 0.93 kg |
| ขนาดบรรจุภัณฑ์ | 302 × 224 × 66 mm |
คำถามเกี่ยวกับสินค้านี้
What PCIe slot size and lane width does the GC-4XM2G4 require?
It needs a PCI Express x16 slot; in an x8 slot only the M2_1 and M2_2 connectors are usable.
How do you install the card and what step is often missed?
Insert the card into a PCIe x16 slot, secure it with the bracket screw, install up to four M.2 SSDs into the keyed M slots, then connect the fan power cable so active cooling works.
What maintenance will the cooling system need later?
The dual-ball bearing fan and thermal pads should be checked periodically for dust build-up and pad degradation to keep both sides of the SSDs cool.
