Black 80mm square case fan with transparent blades and 3-pin connector

Link Depot Corp.

Link Depot Corp. FAN-8025-B 80mm 3000 RPM 38.2 CFM 32.1 dBA case fan

SKU CH-R42C-ZKNT8 MPN FAN-8025-B

80mm ball-bearing case fan delivers 38.2 CFM at 3000 RPM with 32.1 dBA noise over a 3-pin connector

  • Fan Counts1 Fan
  • Fan ControllerNo Controller
  • TypeCase Fan
  • CompatibilityCase
  • Fan Size80mm
  • Fan Thickness25mm
  • High airflow of 38.2 CFM for effective case cooling
  • Ball bearing design for reliable long-term operation
  • 3000 RPM speed delivers strong cooling performance
  • Low noise output at 32.1 dBA for quieter systems
  • Standard 80mm size fits compatible computer cases

Compact 80mm case fan for tight spaces

This 80 by 80 by 25 millimetre fan fits small chassis and restricted mounting points where larger rotors cannot be installed. It delivers 38.2 CFM at 3000 RPM using a ball bearing for durable operation. The unit ships new in black with a single three‑pin power connector.

Three‑pin voltage control limits speed adjustment

The three‑pin connector relies on motherboard voltage regulation rather than PWM signalling, so minimum speed and fine‑grained curves depend on the board implementation. At full voltage the fan runs at a fixed 3000 RPM producing 32.1 dBA. Builders who need quieter idle or software‑defined curves should verify their header capabilities.

Check mounting holes and header type before ordering

Ensure the case provides 80mm screw holes with 25mm clearance for the frame thickness. Confirm the motherboard offers a three‑pin fan header; a four‑pin header will work but will not add PWM control. The fan includes no controller, so speed management is handled entirely by the system firmware.

أبرز المميزات

  • High airflow of 38.2 CFM for effective case cooling
  • Ball bearing design for reliable long-term operation
  • 3000 RPM speed delivers strong cooling performance
  • Low noise output at 32.1 dBA for quieter systems
  • Standard 80mm size fits compatible computer cases

المواصفات

BrandLink Depot
ModelFAN-8025-B
Fan Counts1 Fan
Fan ControllerNo Controller
TypeCase Fan
CompatibilityCase
Fan Size80mm
Fan Thickness25mm
Bearing TypeBall
RPM3000 RPM
Air Flow38.2 CFM
Noise Level32.1 dBA
Power Connector3 Pin
ColorBlack
Dimensions80 x 80 x 25mm
وزن الشحنة0.06 kg
أبعاد الطرد185 × 132 × 28 mm

أسئلة حول هذا المنتج

Should I choose the 80mm 3000 RPM version or a different size for my case?

This model is an 80mm by 25mm fan; verify your case has an 80mm mounting location before ordering.

What does 38.2 CFM at 3000 RPM mean for actual cooling inside my PC?

At 3000 RPM the fan moves 38.2 CFM of air through an 80mm frame, giving strong spot cooling for tight spaces or GPU heatsinks.

The fan uses a 3-pin connector — what does that limit for speed control?

A 3-pin connector allows voltage-based speed control but not PWM; the motherboard can still lower RPM by reducing voltage.
