Green circuit board with four RJ45 ports and a PCIe bracket

STARTECH

STARTECH ST4000PEXPSE 4-port Gigabit PoE network card

SKU CH-JNXE-19ZTZ MPN ST4000PEXPSE

Adds four Gigabit PoE ports via PCI Express, each delivering up to 48 V and 25.5 W under IEEE 802.3at

  • Speed10/100/1000Mbps
  • InterfacePCI-Express
  • FeaturesProduct Type:Gigabit Ethernet Card
  • Weight0.8
  • Package Contents4 Port Gigabit Power over Ethernet PCIe Network Card - PSE /

Option PCIe 1 Gbps PoE - 4 Port RJ45

  • Mini PCIe 1 Gbps - 1 Port RJ45
  • PCIe 1 Gbps - 1 Port RJ45
  • PCIe 1 Gbps - 1 Port RJ45 Low Profile
  • PCIe 1 Gbps - 2 Port RJ45
  • PCIe 1 Gbps PoE - 2 Port RJ45
  • PCIe 1 Gbps - 4 Port RJ45
  • PCIe 1 Gbps PoE - 4 Port RJ45

الإصدارات المشطوبة موجودة، لكنها غير متوفرة هنا.

  • Add four PoE+ ports to a desktop via PCI Express
  • Each port delivers up to 25.5 W at 48 V to powered devices
  • Compliant with IEEE 802.3at Type 1 and Type 2 standards
  • Built-in SATA and LP4 Molex connectors supply PoE power budget
  • Supports 9K jumbo frames and Wake-on-LAN for remote management

Four PoE ports on one card

The StarTech ST4000PEXPSE adds four Gigabit Ethernet ports with Power over Ethernet to a desktop computer through a single PCI Express slot. Each port complies with IEEE 802.3at Type 1 and Type 2 standards and can deliver up to 48V and 25.5 Watts to connected devices such as IP cameras or wireless access points.

Built-in power connectors remove the need

The card draws PoE power directly from the system through a SATA connector and an LP4 Molex connector, so no separate power supply or mid-span injector is required. A driver disc and instruction manual are included for installation on supported operating systems.

25.5 Watts per port decides the device budget

The maximum output of 25.5 Watts per port determines which powered devices can be used; hardware that demands more power per port will not operate correctly. Builders who need higher per-port power or more than four PoE connections must choose a different solution.

أبرز المميزات

  • Add four PoE+ ports to a desktop via PCI Express
  • Each port delivers up to 25.5 W at 48 V to powered devices
  • Compliant with IEEE 802.3at Type 1 and Type 2 standards
  • Built-in SATA and LP4 Molex connectors supply PoE power budget
  • Supports 9K jumbo frames and Wake-on-LAN for remote management

المواصفات

BrandStarTech.com
ModelST4000PEXPSE
Speed10/100/1000Mbps
InterfacePCI-Express
FeaturesProduct Type:Gigabit Ethernet Card
Weight0.8
Package Contents4 Port Gigabit Power over Ethernet PCIe Network Card - PSE / PoE PCI Express NIC
1 x Driver CD
1 x Instruction Manual
وزن الشحنة0.44 kg
أبعاد الطرد295 × 191 × 71 mm

إصدارات أخرى من هذا الطراز

1 أخرى من الفئة نفسها

نفس الفئة، بذاكرة أو مبرّد أو تردد مختلف — قارن قبل أن تقرر.

أسئلة حول هذا المنتج

Will the SATA or Molex power connector need replacement after extended use?

The card draws PoE power through a built-in SATA and LP4 Molex connector; these are standard internal cables and do not require scheduled replacement.

What limits total PoE output when all four ports run at full load?

Each port delivers up to 48V, 25.5 Watts max. output per port under IEEE 802.3at, so the combined draw depends on how many devices request full power simultaneously.

Does the card generate noticeable heat or fan noise during all-day operation?

The card has no integrated fan; heat dissipates passively through the bracket and PCB, so acoustic output is zero while thermal load stays within normal chassis airflow.
