Gray 21.5 inch fanless all-in-one with flat IP65 capacitive touchscreen

partaker

Partaker A30 all-in-one PC, i3-5005U, 8GB, 128GB, 21.5" IP65 touch, Windows 11 Pro

SKU CH-X2TW-T2Z5Y

Industrial 21.5" IP65 all-in-one with fanless cooling, Core i3-5005U, 8 GB DDR3L, 128 GB SSD and Windows 11 Pro

  • TypeAll-in-One PC
  • Form FactorAll-in-One
  • ColorGray
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i3 5th Gen
  • CPU NameIntel Core i3-5005U

A30 21.5" Capacitive I3 5005U 8GB RAM / 128GB SSD

  • IP65 front panel resists dust and water in harsh environments
  • Fanless aluminum chassis runs silently from -20 °C to 60 °C
  • Capacitive touch rated for over 50 million touches
  • Dual Gigabit LAN plus four USB 3.0 ports for industrial connectivity
  • Windows 11 Pro pre-installed on 128 GB SSD with 8 GB DDR3L memory

Industrial Panel PC with IP65 Front

The Partaker A30 is a 21.5 inch all-in-one computer built for factory floors and automation cells. Its flat capacitive touchscreen carries an IP65 rating on the front panel, resisting water jets and dust while surviving over 50 million touches. An Intel Core i3-5005U processor, 8 GB of DDR3L memory and a 128 GB mSATA SSD run Windows 11 Pro for familiar software compatibility.

Fanless Thermal Design for Continuous Duty

Passive aluminium cooling removes moving parts, so the system operates silently and without dust ingestion during 24/7 shifts. The platform is rated for ambient temperatures from -20 °C to 60 °C and humidity between 5 % and 95 % non-condensing, letting it stay online through seasonal extremes. Auto power-on, Wake on LAN and a 0-255 level watchdog timer keep processes recovering unattended after power events.

Rich Industrial I/O and Flexible Mounting

Dual COM ports support RS232 and RS485 for legacy PLCs, while two Gigabit LAN ports and four USB 3.0 connectors handle modern peripherals. Two Mini PCIe slots with a SIM socket allow wireless or cellular expansion without opening the chassis. The unit accepts 12 V DC standard input with an optional 9-36 V wide-range variant, and mounts embedded, wall, desktop or cantilever using the included clips.

Přednosti

  • IP65 front panel resists dust and water in harsh environments
  • Fanless aluminum chassis runs silently from -20 °C to 60 °C
  • Capacitive touch rated for over 50 million touches
  • Dual Gigabit LAN plus four USB 3.0 ports for industrial connectivity
  • Windows 11 Pro pre-installed on 128 GB SSD with 8 GB DDR3L memory

Specifikace

TypeAll-in-One PC
Form FactorAll-in-One
ColorGray
Operating SystemWindows 11 Pro
CPU TypeIntel Core i3 5th Gen
CPU NameIntel Core i3-5005U
Screen Size21.5"
Screen TypeMulti-Touch Screen

Další verze tohoto modelu

Dalších 5 v této řadě

Stejná řada, jiná paměť, chladič nebo takt — porovnejte, než se rozhodnete.

Otázky k tomuto produktu

How much heat and noise does the fanless aluminum cooling produce during 24/7 operation?

The passive aluminum cooling is completely silent and dust-free, with no moving parts, and is rated for continuous operation from -20 °C to 60 °C.

What power input and mounting hardware must I already have to install this panel PC?

It requires a standard 12 V DC supply (100-240 V AC adapter included) and ships with four embedded mounting clips for panel-mount cut-outs of 528 x 320 mm.

Can I keep using my RS-485 devices and dual Gigabit LAN cables with the A30?

Yes, the A30 provides two COM ports supporting RS-232/485 and two Realtek Gigabit LAN ports for direct connection to existing industrial networks.
