Green circuit board with metal bracket, two blue USB-C and three blue USB-A ports facing outward

ESTONE

ESTONE PCIE23A2C 5-Port PCIe USB 3.0 Card (2×USB-C, 3×USB-A)

SKU CH-AMQV-M581X

Adds five USB 3.0 ports — two USB-C and three USB-A — through a PCI Express x1 slot with up to 5 Gbps transfer speed

  • TypePCI to USB Card
  • External USB Ports5x USB Ports
  • StandardUSB 3.0
  • Data Transfer RateUp to 5.0 Gbps
  • Operating Systems SupportedWindows 7/8/10/11
  • CompatibilityWidely Compatibility: The card is compatible with Windows 7/
  • Add five USB 3.0 ports via one PCIe x1 slot
  • Up to 5.0 Gbps data transfer per port
  • Works with Windows 7/8/10/11 and Mac OS 10.8.2+
  • Powered from the PCIe slot, no extra cable needed
  • Each port has independent over-current and short-circuit protection

Expansion Card Overview

The ESTONE PCIE23A2C is a PCI Express x1 add-in card that adds five USB 3.0 ports to a desktop system. It provides two USB-C and three USB-A connectors for users who need more front-panel connectivity. The card supports Windows 7 through 11 and Mac OS 10.8.2 or later with a driver installation. It is intended for builders expanding peripheral support on an existing platform.

Build Integration

The card occupies a single PCI Express x1 slot and draws power directly from the bus, so no external power cable is required. Each port can deliver up to 5 V at 1 A for connected devices, with independent over-current and short-circuit protection. It is backward compatible with USB 2.0 and 1.1 peripherals. The package includes a driver CD, mounting screws, and a user manual for setup.

Sustained Operation

The onboard FRE100 host controller manages a total bandwidth of up to 5.0 Gbps shared across all five ports. Actual throughput depends on the connected device and system configuration. The design includes multiple power modules to maintain stable current delivery during continuous data transfers. The card does not support Power Delivery fast charging, video output, or Thunderbolt protocols.

Besonderheiten

  • Add five USB 3.0 ports via one PCIe x1 slot
  • Up to 5.0 Gbps data transfer per port
  • Works with Windows 7/8/10/11 and Mac OS 10.8.2+
  • Powered from the PCIe slot, no extra cable needed
  • Each port has independent over-current and short-circuit protection

Technische Daten

BrandESTONE
SeriesPCIE23A2C
ModelPCIE23A2C
TypePCI to USB Card
External USB Ports5x USB Ports
StandardUSB 3.0
Data Transfer RateUp to 5.0 Gbps
Operating Systems SupportedWindows 7/8/10/11
CompatibilityWidely Compatibility: The card is compatible with Windows 7/8/10/11 (32/64 bit) and Mac OS 10.8.2 and above. The card only requires installing a driver which you can download from our CD driver, when operating on Windows 7. Note: Windows XP,/Vista/7, Server,requires driver installation, Windows 10/11 and Mac OS and Linux don't need drivers.
Specifications5 Ports PCI-E to USB 3.0 HUB PCI Express Expansion Card Adapter 5Gbps for Motherboard
You need to install the RENESAS/VLI USB3.0 driver for your computer first.
Supports PCI Express 2.0 X1 lane, can transferring up to 5Gbps.
PCI Express x1 slot card for usb expansion 7 Ports USB interface Card (2X USB-C - 5X USB-A)
Power Input: no need extral Power Connector
Power output: +/-5V / 900mA (each port)
Compatible: USB1.1/2.0/3.0
Operating Systems: Windows7/8/10(32/64bit)
?
FeaturesPCI Express x1 slot card for usb expansion 5 Ports USB interface Card (2X USB-C - 3X USB-A)
USB3.0 Backwards compatible older USB 2.0 and 1.1 devices; Comply with PCI-e 3.0 PCIe 2.0 motherboards, Fits PCI Express x1, x4, x8 or x16 socket .Operating System Supports Windows XP/Vista/2008 Server/7/8/10,and Mac 0s (10.8.2 above) . Note: Windows XP,/Vista/7, Server,requires driver installation, Windows 10 and Mac OS 10.8.2 above don't need drivers.
transfer rates of up to 5Gbps copying HD videos, music, photos,data files between USB devices and the computer at blazing fast speeds.Note:The
Dimensions4.92 x 4.06 x 1.06 inches
Weight3.2 ounces
Package Contents1x USB 3.0 PCI-E expansion card, 1x CD driver, 1 x installation screws, and 1x user manual.

Fragen zu diesem Artikel

What total bandwidth does the PCIe 2.0 x1 link provide when all five ports are active?

The card uses a PCI Express 2.0 x1 lane, which limits aggregate throughput to 5.0 Gbps shared across the two USB-C and three USB-A ports.

Does the card need extra cooling or a fan when running all day?

No external power adapter is required; the board draws 5 V / 12 A maximum from the PCIe slot and has no active cooling, so it runs silently under sustained load.

Which operating systems are supported without extra driver hunting?

Windows 7, 8, 10 and 11 (32-bit and 64-bit) plus Mac OS 10.8.2 and later are listed as compatible; a Renesas/VLI USB 3.0 driver install is needed on Windows.
