Small tall silver mini PC barebone with VESA mount bracket visible

ASUS

ASUS NUC13ANHHi5 Core i5-13420H barebone mini PC

SKU CH-CQMX-2RBHA MPN NUC13ANHHi5

A barebone mini PC ready for DDR4 memory and dual NVMe storage, driven by an 8-core Intel Core i5-13420H with 2.5Gbps LAN, Wi-Fi 6E and Thunderbolt 4 for quad 4K output

  • Form FactorTall
  • CPU TypeIntel Core i5-13420H
  • CPU Cores8-Core (4P+4E)
  • Memory installedNo Memory
  • Memory slot2 x 260Pin SO-DIMM
  • Memory Type SupportedDDR4 3200

Option Barebone

  • 8-core 13th Gen Intel Core i5 processor handles demanding workloads
  • Dual-channel DDR4 3200 support up to 64 GB for responsive multitasking
  • Two M.2 slots (2280 Gen4 and 2242 Gen3) enable fast NVMe storage expansion
  • 5 Gbps Ethernet plus Wi-Fi 6E and Bluetooth 5.3 deliver high-speed wired and wireless connectivity
  • VESA mount included for space-saving behind-monitor or wall installation

Tall barebone for compact productivity

The ASUS NUC 13 Pro Tall barebone kit delivers a 13th Gen Intel Core i5-13420H processor with eight cores and integrated Intel UHD Graphics in a 4x4 form factor. It targets offices, digital-signage deployments and home labs that need quiet, VESA-mountable performance without a full-size tower. Buyers add their own DDR4 memory and NVMe storage to match the workload. The kit includes a Kensington lock slot and cable-locking arm for physical security in shared spaces.

Verify memory, storage and mount clearance

Confirm you have two DDR4 3200 SO-DIMM modules up to 64 GB total for dual-channel operation, as no memory is installed. The board provides one M.2 2280 PCIe Gen4x4 slot and one M.2 2242 PCIe Gen3 slot, both keyed for NVMe drives; no 2.5-inch bay is present. Ensure the mounting surface accepts the supplied VESA bracket and that rear I/O clearance fits your cables. Wireless uses Intel Wi-Fi 6E AX211 and Bluetooth 5.3; wired LAN is 2.5 Gbps via Intel i226V.

Sustained 24/7 operation with multi-display output

The system is qualified for continuous 24/7 duty, so thermals are tuned for long renders, signage loops or server tasks rather than short bursts. Dual HDMI and dual DisplayPort via Thunderbolt 4 Type-C ports drive up to one 8K or four 4K 60 Hz displays simultaneously. Integrated UHD Graphics handles desktop composition and video decode steadily under load. Expansion bay accepts optional add-on modules for extra I/O without increasing chassis height.

Points forts

  • 8-core 13th Gen Intel Core i5 processor handles demanding workloads
  • Dual-channel DDR4 3200 support up to 64 GB for responsive multitasking
  • Two M.2 slots (2280 Gen4 and 2242 Gen3) enable fast NVMe storage expansion
  • 5 Gbps Ethernet plus Wi-Fi 6E and Bluetooth 5.3 deliver high-speed wired and wireless connectivity
  • VESA mount included for space-saving behind-monitor or wall installation

Caractéristiques

BrandASUS
SeriesNUC 13 Pro
ModelNUC13ANHHi5
Form FactorTall
CPU TypeIntel Core i5-13420H
CPU Cores8-Core (4P+4E)
Memory installedNo Memory
Memory slot2 x 260Pin SO-DIMM
Memory Type SupportedDDR4 3200
Max Memory Supported64GB
Dual Channel Memory SupportedYes
Storage InstalledNo Hard Drive
M.2 Slot1 x M.2 2280 PCIe Gen4x4 NVMe SSD Slot (key M)
1 x M.2 2242 PCIe Gen3 NVMe SSD Slot (key B)
Integrated GraphicsIntel UHD Graphics
Onboard AudioRealtek ALC269
Channel2 Channel
LANIntel i226V
Max LAN Speed2.5Gbps
Wireless LANIntel Wi-Fi 6E AX211 (Gig+), 2x2
WiFi GenerationWi-Fi 6E
BluetoothBluetooth 5.3
2.5" Internal Bays1 x 2.5-inch SATA 6Gb/s support for HDD (supports up to 4TB)
Front USB1 x USB 3.2 Gen2 Type-A (with BC1.2 5V/0.9A, 10Gbps)
1 x USB 3.2 Gen2 Type-A (5V/0.9A, 10Gbps)
Front Audio Ports1 x 3.5mm Audio Jack (Line out/Mic in/Headphone out)
HDMI2 x HDMI 2.1 (with TMDS, up to 4K@60Hz)
Thunderbolt2 x Thunderbolt 4 (with DP1.4 / 5V/3A, 40Gbps)
Rear USB1 x USB 3.2 Gen2 Type-A (5V/0.9A, 10Gbps)
1 x USB 2.0 Type-A (5V/0.5A, 480Mbps)
RJ451 x Intel 2.5G LAN (RJ45)
Other Rear Ports1 x Kensington Lock Slot
1 x Cable Locking Arm
1 x DC-in
Power Supply120W Power Adapter
Dimensions4.61" x 4.41" x 2.13"
Weight1.3 lbs
PackagingVESA Mount & Screws / AC Power Adapter / Power Cord, US Cord for USA

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Does the ASUS NUC13ANHHi5 ship with RAM or an SSD, and what must I add?

The unit is a barebone kit with no memory and no storage installed. You must add two DDR4 3200 SO-DIMMs up to 64 GB total and choose an M.2 2280 PCIe Gen4 NVMe drive plus an M.2 2242 PCIe Gen3 NVMe drive.

Which DDR4 capacity should I pick for the two SO-DIMM slots?

Install two matching DDR4 3200 modules for dual-channel operation; the board supports up to 64 GB total, so 2 × 32 GB is the maximum.

What does the 2.5 Gbps LAN port deliver in everyday file transfers?

The Intel i226V controller provides a 2.5 Gbps wired link, so large copies between this NUC and other 2.5 GbE devices run at the full line rate instead of being limited to 1 Gbps.
