Black ATX motherboard with silver heatsinks, two DIMM slots and a boxed Intel Core Ultra 7 265K CPU alongside

ASUS

ASUS ROG MAXIMUS Z890 APEX Intel motherboard & Core Ultra 7 265K CPU Combo

SKU CH-G09J-B8JKJ

Z890 ATX motherboard paired with a Core Ultra 7 265K CPU, DDR5 to 9600 MT/s, 5G LAN, WiFi 7, Thunderbolt and three PCIe 5.0 M.2 slots

  • CPU Socket TypeLGA 1851
  • CPU TypeIntel Core Ultra Processors (Series 2)
  • ChipsetIntel Z890
  • Number of Memory Slots2x288pin (DDR5)
  • Maximum Memory Supported128GB
  • Channel SupportedDual Channel

Motherboard ROG MAXIMUS Z890 APEX

+CPU +Ultra 7 265K

  • Ready for advanced AI PCs with Intel Core Ultra 265K 3nm processor
  • AI overclocking, cooling and networking simplify setup and boost performance
  • Robust 22 plus 2 plus 1 plus 2 stage power design with 110A, 90A and 80A stages
  • DDR5 memory up to 9600 MT/s supported via DIMM Fit and AEMP III
  • WiFi 7, Bluetooth 5.4 and 5Gbps LAN deliver fast wireless and wired connectivity

LGA 1851 AI-ready platform

The ASUS ROG MAXIMUS Z890 APEX motherboard paired with the Intel Core Ultra 7 265K processor delivers a high-end Intel LGA 1851 platform built for advanced AI workloads. The 3nm Arrow Lake CPU operates at a 125W base power with 30MB L3 cache and 36MB L2 cache. Integrated Intel Graphics provide display output without a discrete card. This combination targets enthusiasts who want AI acceleration, overclocking headroom and extensive connectivity in a single package.

DDR5 9600 MT/s and PCIe 5.0 limits

Dual-channel DDR5 memory tops out at 128GB across two 288-pin slots with support for speeds up to 9600 MT/s when overclocked. The primary PCIe 5.0 x16 slot and first M.2 socket share CPU lanes, so populating M.2_3 forces the top graphics slot to x8 and the second to x4. Four SATA 6Gb/s ports and three additional M.2 slots (one PCIe 5.0, two PCIe 4.0) provide storage flexibility within those lane constraints. WiFi 7 and Bluetooth 5.4 handle wireless duties.

22+2+1+2 power stages and 5G LAN headroom

The 22+2+1+2 phase VRM uses 110A, 90A and 80A power stages to feed the 265K and high-speed memory with ample overhead for sustained loads. Dual Thunderbolt 4 ports, one 20Gbps USB-C, four 10Gbps Type-A and four 5Gbps Type-A ports on the rear I/O cover most peripheral needs. Onboard headers add another 20Gbps USB-C, one 10Gbps USB-C, four 5Gbps and four 2.0 ports. The 5Gbps Ethernet jack and WiFi 7 ensure network throughput matches the platform's I/O capacity.

Points forts

  • Ready for advanced AI PCs with Intel Core Ultra 265K 3nm processor
  • AI overclocking, cooling and networking simplify setup and boost performance
  • Robust 22 plus 2 plus 1 plus 2 stage power design with 110A, 90A and 80A stages
  • DDR5 memory up to 9600 MT/s supported via DIMM Fit and AEMP III
  • WiFi 7, Bluetooth 5.4 and 5Gbps LAN deliver fast wireless and wired connectivity

Caractéristiques

BrandASUS
SeriesROG MAXIMUS Z890 APEX+Ultra 7 265K
ModelROG MAXIMUS Z890 APEX+Ultra 7 265K
CPU Socket TypeLGA 1851
CPU TypeIntel Core Ultra Processors (Series 2)
ChipsetIntel Z890
Number of Memory Slots2x288pin (DDR5)
Maximum Memory Supported128GB
Channel SupportedDual Channel
Memory FeatureSupports up to 9600+ MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*
Dual Channel Memory Architecture
DIMM Fit
Supports Intel Extreme Memory Profile (XMP) memory module
Supports DIMM Flex
ASUS Enhanced Memory Profile III (AEMP III)
* Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
PCI Express 5.0 x16Support Intel Core Ultra Processors(series 2)*
2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 or x8/x4/x4 modes)**
PCI Express x42 x PCIe 4.0 x4 slots
** M.2_3 & M.2_4 share bandwidth with PCIEX16(G5)_2. When M.2_3 is enabled, PCIEX16(G5)_1 will run x8 & PCIEX16(G5)_2 will run x4. When M.2_3 & M.2_4 are enabled, PCIEX16(G5)_1 will run x8 & PCIEX16(G5)_2 will disabled.
Serial ATA (SATA)4 x SATA 6Gb/s
M.2Support Intel Core Ultra Processors(series 2) *
M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 modes)**
M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 modes)**
Intel Z890 Chipset
DIMM.2_1 slot (Key M) via ROG DIMM.2, type 2230/2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
DIMM.2_2 slot (Key M) via ROG DIMM.2, type 2230/2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
**M.2_3 & M.2_4 share bandwidth with PCIEX16(
Audio ChannelsROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*
- Impedance sense for front and rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
- High quality 120 dB SNR stereo playback output and 110 dB SNR recording input
- Supports up to 32-Bit/384 kHz playback on front panel
Audio Features
- SupremeFX Shielding Technology
- Savitech SV3H712 AMP
- Gold-plated audio jacks
- Rear optical S/PDIF out port
- Premium audio capacitors
- Audio cover
* A chassis with an HD audio module in the front panel is required to support 7.1 Su
Max LAN Speed5Gbps
Wireless LANWi-Fi 802.11 be
BluetoothBluetooth 5.4
Back I/O Ports2 x Thunderbolt 4 ports (USB Type-C)
1 x USB 20Gbps port (1 x USB Type-C)
4 x USB 10Gbps ports (4 x Type-A)
4 x USB 5Gbps ports (4 x Type-A)
1 x Wi-Fi Module
1 x Realtek 5Gb Ethernet port
2 x Gold-plated audio jacks
1 x Optical S/PDIF out port
1 x BIOS FlashBack button
1 x Clear CMOS button
1 x PS/2 keyboard/mouse combo port
Onboard USB1 x USB 20Gbps connector (supports USB Type-C)
1 x USB 10Gbps connector (supports USB Type-C)
2 x USB 5Gbps headers support 4 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Other ConnectorsFan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
2 x 4-pin Chassis Fan headers
2 x 4-pin Full Speed Fan headers
1 x W_PUMP+ header
1 x Extra Flow Fan header
Miscellaneous
1 x 80 Light Bar jumper
3 x Addressable Gen 2 headers
1 x Alteration PCIe mode switch
4 x BCLK button
1 x BIOS Switch button
1 x FlexKey button
1 x Front Panel Audio header (F_AUDIO)
1 x LN2 Mode jumper
1 x Pause switch
18 x ProbeIt Measurement Points
1 x ReTry button
2 x RSVD switches
1 x RSVD header
1 x Safe Boot button
1 x Slow Mode switch
1 x Start button
1
BIOS Feature2 x 256 Mb Flash ROM, UEFI AMI BIOS
SoftwareROG Exclusive Software
- ROG CPU-Z
- Dolby Atmos
- Internet Security (1-year full version)
ASUS Exclusive Software
Armoury Crate
- AIDA64 Extreme (1 year full version)
- Aura Creator
- Aura Sync
- Fan Xpert 4 (with AI Cooling II)
- GameFirst
- Power Saving
- HWiNFO
ASUS AI Advisor
ASUS Driver Hub
ASUS GlideX
Turbo Vcore
Adobe Creative Cloud (Free Trial)
Thunderbolt Share
USB Wattage Watcher
WinRAR (40 Days Free Trial)
UEFI BIOS
AI Overclocking Guide
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
- ASUS MyHotkey
NPU Boost
Windows 11Windows 11 (22H2 & later), Windows 10 64-bit (21H2 & later)
Form FactorATX
Dimensions (W x L)12.0" x 9.6"
Power Pin1 x 24-pin Main Power connector
2 x 8-pin +12V Power connector
1 x 8-pin PCIe Power connector
FeaturesExtreme OC Kit
- FlexKey button
- LN2 Mode
- ProbeIt
- ReTry button
- Safe boot button
- Start button
- Slow Mode
Extreme Engine Digi+
- SMD Capacitor
- MicroFine Alloy Choke
ASUS Q-Design
- M.2 Q-Latch
- M.2 Q-Release
- M.2 Q-Slide
- PCIe Slot Q-Release Slim (with PCIe SafeSlot)
- Q-Antenna
- Q-Code
- Q-Dashboard
- Q-Connector
- Q-DIMM
- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
- Q-Slot
ASUS Thermal Solution
- M.2 heatsink backplate
- M.2 heatsink
- VRM heatsink design
ASUS EZ DIY
- BIOS FlashBack button
- Clear CMOS button
- CPU Socket lever protect

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Should I choose the 128 GB DDR5 maximum or a smaller kit for the two DIMM slots?

The board has two DDR5 slots supporting up to 128 GB total in dual-channel mode. A two-module kit matching that capacity fills both slots and enables the rated 9600+ MT/s overclocked speeds with XMP or AEMP III profiles.

What does the Core Ultra 7 265K 125 W base power mean for my cooling and VRM choice?

The CPU is rated at 125 W base power and uses the LGA 1851 socket. The motherboard provides 22+2+1+2 power stages rated at 110 A, 90 A, 90 A and 80 A respectively, with ProCool II connectors, MicroFine alloy chokes and metallic capacitors to handle sustained loads.

Which PCIe generation do the three M.2 slots use and how does bandwidth sharing work?

M.2_1 runs PCIe 5.0 x4, M.2_2 runs PCIe 4.0 x4, while M.2_3 and M.2_4 share bandwidth with the second PCIe 5.0 x16 slot. Enabling M.2_3 forces that slot to x4 and the primary to x8; enabling both M.2_3 and M.2_4 keeps the primary at x8 and the secondary at x4.
