Compact silver mini PC with front USB ports and audio jack

BRE NUC

BRE NUC N7P Ryzen 7 7840HS 64GB DDR5 1TB barebone mini PC

SKU CH-W9GX-MW8GS MPN N7P

Compact barebone with Ryzen 7 7840HS, 64 GB DDR5, 1 TB PCIe 4.0 SSD, triple 4K output and dual 2.5 GbE LAN

  • CPU TypeAMD Ryzen 7 7840HS
  • Memory slot2 x 288Pin DIMM
  • Memory Type SupportedDDR5 5600
  • Max Memory Supported64GB
  • Dual Channel Memory SupportedYes
  • Storage InstalledNo Hard Drive

Group 64GB RAM / 1TB SSD

  • 8-core Ryzen 7 7840HS reaches 5.1 GHz for heavy workloads
  • Radeon 780M graphics with 12 CUs at 2.7 GHz drives 4K gaming
  • Dual-channel DDR5 5600 memory up to 64 GB handles data-intensive tasks
  • Triple 4K output via HDMI 2.0, DP1.4a and USB4 40 Gbps expands workspaces
  • Dual 2.5 GbE LAN plus WiFi 6 and Bluetooth 5.2 ensures low-latency connectivity

Compact Ryzen 7 7840HS mini PC

The BRE NUC N7P is a 136 x 123 x 51 mm barebone system built around an 8-core, 16-thread AMD Ryzen 7 7840HS processor with integrated Radeon 780M graphics. It ships with 64 GB of dual-channel DDR5 5600 memory and a 1 TB PCIe 4.0 SSD already installed. The platform targets creators, developers and gamers who need desktop-class compute in a VESA-mountable chassis that runs Windows 11 Pro out of the box.

Thermals and 120 W power profile

A 19 V 5.26 A external adapter supplies up to 120 W to the unit, which is rated for continuous operation between -10 °C and 45 °C at 30–85 % humidity. The Zen 4 mobile processor scales up to 5.1 GHz while the Radeon 780M reaches 2.7 GHz, both cooled by an internal solution designed for the compact enclosure. Dual 2.5 GbE Intel i226V controllers, Wi-Fi 6 and Bluetooth 5.2 maintain connectivity without adding significant thermal load during typical workloads.

Connectivity and mounting practicality

The front panel provides two USB 3.2 Gen 2 Type-A ports, one USB 3.2 Gen 2 Type-C port and a 3.5 mm headset jack for quick peripheral access. Rear I/O adds a USB4 40 Gbps port, two USB 2.0 Type-A ports, HDMI 2.0, DisplayPort 1.4a and the second DisplayPort 1.4a channel routed through the USB-C interface, enabling triple 4K 60 Hz displays. Two M.2 2280 key-M slots accept PCIe 4.0 x4 NVMe drives for storage expansion, while the included VESA bracket allows the unit to be mounted behind a monitor or under a desk.

Points forts

  • 8-core Ryzen 7 7840HS reaches 5.1 GHz for heavy workloads
  • Radeon 780M graphics with 12 CUs at 2.7 GHz drives 4K gaming
  • Dual-channel DDR5 5600 memory up to 64 GB handles data-intensive tasks
  • Triple 4K output via HDMI 2.0, DP1.4a and USB4 40 Gbps expands workspaces
  • Dual 2.5 GbE LAN plus WiFi 6 and Bluetooth 5.2 ensures low-latency connectivity

Caractéristiques

BrandBRENUC
SeriesN7P
ModelN7P 7840HS
CPU TypeAMD Ryzen 7 7840HS
Memory slot2 x 288Pin DIMM
Memory Type SupportedDDR5 5600
Max Memory Supported64GB
Dual Channel Memory SupportedYes
Storage InstalledNo Hard Drive
M.2 Slot2 x M.2
Discrete Graphic CardAMD Radeon™ 780M
Onboard AudioIntegrated
Channel7.1 Channel
LANIntel i226V
Max LAN Speed2.5Gbps
Wireless LAN802.11ax
WiFi GenerationWi-Fi 6
BluetoothBluetooth 5.2
Front USB2 x USB 3.2Gen2 (10Gbps ) Type-A
1 x USB 3.2 Gen2 (10Gbps ) Type-C
Front Audio Ports3.5mm Audio Jack
HDMI1 x HDMI 2.0
DisplayPort1 x DP1.4
Rear USB2 x USB 2.0 Type-A
1 x USB 4
RJ452 x 2.5Gb RJ45
Input19V/5.26A
Power Supply120W
Dimensions136mm*123mm*51mm
PackagingIndividual retail box packaging

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

How do I install the DDR5 SODIMM modules into the two 288-pin slots and what step is often missed?

Power off, unplug the 19V 5.26A adapter, remove the bottom cover, insert each module at 45° until the clips click, then reattach the cover before powering on; the missed step is forgetting to seat both clips fully.

What maintenance will the cooling system need after extended use?

The internal fan and heatsink should be cleared of dust every 6–12 months using compressed air through the ventilation grilles; no liquid-metal repaste or pad replacement is required by design.

What thermal or power limit appears first during sustained all-core workloads?

The 120 W power adapter and the 45 °C maximum operating temperature constrain the Ryzen 7 7840HS before the Radeon 780M hits its 2.7 GHz ceiling.
