Compact square mini PC in dark grey plastic with silver accents

BRENUC

BRENUC BREC barebone mini PC Core Ultra 9 285H 96GB 4TB Arc 140T

SKU CH-2DH1-TWFJC

Intel Core Ultra 9 285H mini PC barebone supports 96 GB DDR5, 4 TB NVMe, Arc 140T graphics for four 4K displays, WiFi 6E and Bluetooth 5.3

  • AI FeaturesAI Ready
  • CPU TypeIntel Core Ultra 9 285H
  • CPU Cores14
  • Memory installedNo Memory
  • Memory slot2 x 288Pin DIMM
  • Memory Type SupportedDDR5 5600

Option 96GB RAM / 4TB SSD

  • AI-ready Intel Core Ultra 9 285H with 14 cores up to 5.4 GHz
  • Intel Arc 140T graphics driving four 4K@60 Hz displays via HDMI and Type-C
  • Dual-channel DDR5 5600 supports up to 128 GB for memory-intensive workloads
  • Wi-Fi 6E plus Bluetooth 5.3 for low-latency wireless and stable peripherals
  • 5 GbE LAN, four USB 3.2 Gen2 ports and two full-function Type-C for fast wired connectivity

Intel Core Ultra 9 285H mini PC

The BRENUC BREC is a compact barebone system built around a 16-core Intel Core Ultra 9 285H processor with a 5.4 GHz boost clock. It ships with 96 GB of DDR5-5600 memory in dual-channel configuration and a 4 TB PCIe 4.0 NVMe SSD. Integrated Intel Arc 140T graphics drive up to four 4K 60 Hz displays via two HDMI 2.1 and two USB-C ports. Wireless connectivity uses Wi-Fi 6E and Bluetooth 5.3, while wired networking runs at 2.5 Gbps. A 120 W power adapter is included.

For AI workloads and multi-display stations

Developers and content creators who need local AI acceleration and quad-screen 4K output will match the Core Ultra 9 285H NPU and Arc 140T combination. The 96 GB DDR5 capacity handles large models and datasets without swapping. Buyers who want more storage than the single M.2 2280 slot provides should look elsewhere. Users requiring discrete GPU performance beyond integrated Arc graphics need a larger chassis. The barebone form factor also limits internal expansion to one additional M.2 B-key device.

96 GB DDR5-5600 soldered memory

The 96 GB DDR5-5600 configuration is fixed and cannot be upgraded beyond the two SODIMM slots supporting 128 GB maximum. Verify that this capacity satisfies your workload before purchase, as adding modules later requires replacing the factory kit.

Points forts

  • AI-ready Intel Core Ultra 9 285H with 14 cores up to 5.4 GHz
  • Intel Arc 140T graphics driving four 4K@60 Hz displays via HDMI and Type-C
  • Dual-channel DDR5 5600 supports up to 128 GB for memory-intensive workloads
  • Wi-Fi 6E plus Bluetooth 5.3 for low-latency wireless and stable peripherals
  • 5 GbE LAN, four USB 3.2 Gen2 ports and two full-function Type-C for fast wired connectivity

Caractéristiques

BrandBRENUC
SeriesBREC
ModelIntel Core UItra 9 285H
AI FeaturesAI Ready
CPU TypeIntel Core Ultra 9 285H
CPU Cores14
Memory installedNo Memory
Memory slot2 x 288Pin DIMM
Memory Type SupportedDDR5 5600
Max Memory Supported128GB
Dual Channel Memory SupportedYes
Serial ATA1 x M.2 B-key PCIe Gen3 x1 22x42(SAT3.0)
M.2 Slot1 x M.2 2280 PCIe 4.0 X4 NVMe SSD
Discrete Graphic CardIntel ARC 140T Graphics
Onboard AudioIntegrated
Channel7.1 Channel
Max LAN Speed2.5Gbps
Wireless LAN802.11ax
WiFi GenerationWi-Fi 6E
BluetoothBluetooth 5.3
Front USB2 x USB 3.2 Gen2(10Gbps) Type-A ports
Front Audio Ports3.5mm Audio Jack
Other Front Ports1 x Type-C (USB2.0)
HDMI2 x HDMI 2.1 TMDS
Thunderbolt2 x Type-C Full Function Port
Rear USB2 x USB 3.2 Gen2(10Gbps) Type-A port
RJ451 x 2.5Gb RJ45
Input19VDC /6.32A
Power Supply120W
Dimensions136 x 123 x 51mm
MaterialHigh-density plastic with metal frame
PackagingIndividual retail box packaging

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

What comes in the box and what must I buy separately?

The box contains the BREC mini PC, a 120 W power adapter, a VESA mount and a user manual. Memory modules and storage drives are not included.

Which DDR5 capacity should I choose for the two SODIMM slots?

Install two DDR5 5600 SODIMMs up to a combined 128 GB to run in dual-channel mode.

What does the 2.5 Gbps LAN figure mean in daily use?

The 2.5 Gbps RJ45 port can move data up to 2.5 gigabits per second when connected to a matching switch or router, faster than standard gigabit Ethernet.
