Buffalo TeraStation 3030 two-bay desktop NAS in black with front drive bays and LED indicators

Buffalo Technology

Buffalo Technology TS3230DN0402 2-Bay NAS 4TB 2GB DDR4

SKU CH-ER7S-VCB5F MPN TS3230DN0402

A two-bay desktop NAS with 4 TB of included storage, a quad-core 2.0 GHz processor, 2 GB DDR4 memory, 2.5 GbE and 1 GbE ports plus two USB 3.0 connections, supporting RAID 0, 1 and JBOD

  • TypeDesktop NAS
  • StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
  • Ports1 x 1GbE
  • Port RJ-451 x 2.5GbE + 1 x 1GbE
  • Port USB2 x USB3.0
  • HDD Interface2 x SATA (2 x Bay)

Included HDD Capacity 4TB (2 x 2TB)

  • High read/write performance with RAID 0, 1 and JBOD
  • Quad-core Annapurna Labs Alpine AL-524 processor at 2.0GHz for responsive file operations
  • 4TB total capacity from two pre-installed 2TB drives
  • Dual Ethernet with 2.5GbE and 1GbE ports for flexible network speeds
  • Two USB 3.0 ports for direct external storage or printer sharing

Compact 2-bay NAS with dual Ethernet

The Buffalo TeraStation 3030 TS3230DN0402 is a desktop network-attached storage device pre-populated with two 2 TB drives for a total of 4 TB. An Annapurna Labs Alpine AL-524 quad-core processor at 2.0 GHz and 2 GB of DDR4 memory handle file serving and RAID management. It targets small offices and home users who need straightforward shared storage without configuring drives themselves.

Thermal and power profile

The unit draws 33.88 W under typical operation from a 100-240 VAC 50/60 Hz supply. Operating temperature range is 0°C to 40°C with 10-80 % non-condensing humidity. Two network ports — one 2.5GbE and one 1GbE — provide wired connectivity while the fanless chassis keeps acoustic output low for desk-side placement.

Bundled accessories and software impact

The package includes a quick setup guide, a Cat 5e Ethernet cable, an AC power cable and a front-panel key for drive bay access. These items let a single administrator deploy the NAS and secure the drives without sourcing extra cables or tools. RAID 0, 1 and JBOD modes are selectable during initial configuration to match redundancy or capacity priorities.

Points forts

  • High read/write performance with RAID 0, 1 and JBOD
  • Quad-core Annapurna Labs Alpine AL-524 processor at 2.0GHz for responsive file operations
  • 4TB total capacity from two pre-installed 2TB drives
  • Dual Ethernet with 2.5GbE and 1GbE ports for flexible network speeds
  • Two USB 3.0 ports for direct external storage or printer sharing

Caractéristiques

BrandBUFFALO
SeriesTeraStation 3030
ModelTS3230DN0402
Part NumberTS3230DN0402
TypeDesktop NAS
StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Ports1 x 1GbE
Port RJ-451 x 2.5GbE + 1 x 1GbE
Port USB2 x USB3.0
HDD Interface2 x SATA (2 x Bay)
Form Factor2-Bay
ProcessorAnnapurna Labs Alpine Processor AL-524 2.0GHz Quad-core
Installed Memory2GB DDR4
Included HDD Capacity4TB (2 x 2TB)
RAIDRAID 0, 1 and JBOD
Drive CompatibilityOP-HD2.0N
Supported ProtocolsTCP/IP
LEDsPower, HDD (Hard Disk Drive), LAN (10/100)
Power100-240 VAC 50/60Hz
Power Consumption33.88W
Temperature0°C - 40 °C
Humidity10-80% Non-condensing
UsageHigh read/write performance with RAID
Dimensions9.1 x 6.7 x 6.7 in
Weight9.5 lbs.
Package ContentsTeraStation, Quick Setup Guide, 5e Ethernet Cable, AC Cable, Front Panel Key, and Warranty Statement
Poids d’expédition5.72 kg
Dimensions du colis358 × 320 × 310 mm

Autres versions de ce modèle

2 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

How do I install the included 2TB drives into the 2-bay chassis, and what step is often missed?

Slide each 2TB drive into a bay until the SATA connector seats firmly, then lock the front panel with the supplied key — skipping the lock leaves drives loose and can break the SATA connection.

What maintenance or replacement will the TS3230DN0402 need over time?

The two 2TB drives are the only field-replaceable parts; plan to swap a drive if SMART errors appear or capacity runs out — the 2GB DDR4 memory is soldered and not upgradeable.

What limit appears first during sustained heavy writes on the 2.5GbE port?

The Annapurna Labs AL-524 quad-core processor and 2GB DDR4 become the bottleneck before the 2.5GbE link saturates, capping continuous throughput well below the port's theoretical maximum.
