Rectangular black desktop NAS unit with two drive bays visible on front

Buffalo Technology

Buffalo Technology TS3230DN0802 2-Bay NAS 8TB 2GB DDR4

SKU CH-SWFE-R6EK0 MPN TS3230DN0802

Two-bay desktop NAS with 8 TB pre-installed, quad-core 2.0 GHz processor, 2 GB DDR4, 2.5 GbE and 1 GbE ports, plus two USB 3.0 ports

  • TypeDesktop NAS
  • StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
  • Ports1 x 1GbE
  • Port RJ-451 x 2.5GbE + 1 x 1GbE
  • Port USB2 x USB3.0
  • HDD Interface2 x SATA (2 x Bay)

Included HDD Capacity 8TB (2 x 4TB)

  • Ready-to-use storage with 8 TB pre-installed across two 4 TB drives
  • Quad-core Annapurna Labs AL-524 processor at 2.0 GHz for responsive file serving
  • Dual Ethernet with 2.5 GbE and 1 GbE ports for flexible network speeds
  • RAID 0, 1 and JBOD options to match performance or redundancy needs
  • Two USB 3.0 ports for quick external backup or expansion

Compact two-bay network storage

The Buffalo Technology TS3230DN0802 is a desktop NAS pre-loaded with 8TB across two 4TB drives. An Annapurna Labs Alpine AL-524 quad-core processor running at 2.0GHz and 2GB of DDR4 memory handle file serving for small offices or home labs. It connects through one 2.5GbE and one 1GbE RJ-45 port plus two USB 3.0 ports for external expansion.

RAID flexibility and capacity limits

The unit supports RAID 0, RAID 1 and JBOD so you can choose between maximum capacity, mirroring or independent volumes. Eight terabytes covers typical document, photo and backup workloads; heavier media libraries or virtual machine images will fill the bays quickly. Only OP-HD4.0N drives are listed as compatible, so drive upgrades are restricted to that specific model line.

Included accessories for immediate setup

The package supplies a TeraStation unit, quick setup guide, Cat 5e Ethernet cable, AC power cable, front panel key and warranty statement. No additional drives, rail kits or software licences are bundled, so deployment is limited to the pre-installed configuration and any OP-HD4.0N drives you source separately.

Points forts

  • Ready-to-use storage with 8 TB pre-installed across two 4 TB drives
  • Quad-core Annapurna Labs AL-524 processor at 2.0 GHz for responsive file serving
  • Dual Ethernet with 2.5 GbE and 1 GbE ports for flexible network speeds
  • RAID 0, 1 and JBOD options to match performance or redundancy needs
  • Two USB 3.0 ports for quick external backup or expansion

Caractéristiques

BrandBUFFALO
SeriesTeraStation 3030
ModelTS3230DN0802
Part NumberTS3230DN0802
TypeDesktop NAS
StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Ports1 x 1GbE
Port RJ-451 x 2.5GbE + 1 x 1GbE
Port USB2 x USB3.0
HDD Interface2 x SATA (2 x Bay)
Form Factor2-Bay
ProcessorAnnapurna Labs Alpine Processor AL-524 2.0GHz Quad-core
Installed Memory2GB DDR4
Included HDD Capacity8TB (2 x 4TB)
RAIDRAID 0, 1 and JBOD
Drive CompatibilityOP-HD4.0N
Supported ProtocolsTCP/IP
LEDsPower, HDD (Hard Disk Drive), LAN (10/100)
Power100-240 VAC 50/60Hz
Power Consumption33.88W
Temperature0°C - 40 °C
Humidity10-80% Non-condensing
UsageHigh read/write performance with RAID
Dimensions9.1 x 6.7 x 6.7 in
Weight9.5 lbs.
Package ContentsTeraStation, Quick Setup Guide, 5e Ethernet Cable, AC Cable, Front Panel Key, and Warranty Statement
Poids d’expédition5.72 kg
Dimensions du colis358 × 320 × 310 mm

Autres versions de ce modèle

2 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Will the 2.5GbE and 1GbE ports work with my existing gigabit switch and router?

Yes, the 2.5GbE and 1GbE RJ-45 ports are backward compatible with IEEE 802.3, 802.3u and 802.3ab standards, so they will link at 1GbE or 100Mbps speeds on your current gigabit switch and router.

How do I confirm the Annapurna Labs AL-524 processor and 2GB DDR4 are operating correctly after setup?

Log into the TeraStation 3030 web UI; the System Information page displays the AL-524 2.0GHz quad-core CPU and 2GB DDR4 memory, while the LED panel shows Power, HDD and LAN status for each drive and network link.

What comes in the box and which drives or accessories must I purchase separately?

The package includes the TeraStation 3230DN unit, quick setup guide, Cat 5e Ethernet cable, AC power cable, front panel key and warranty statement; the two 4TB SATA drives are pre-installed, so no additional drives are required for the 8TB RAID 0, 1 or JBOD configuration.
