Buffalo TeraStation 3030 4-bay desktop NAS, black chassis with front drive bays and status LEDs

Buffalo Technology

Buffalo Technology TS3430DN1604 16TB 4-Bay NAS

SKU CH-H1MT-AT76M MPN TS3430DN1604

Four-bay desktop NAS with 16TB pre-installed storage, quad-core processor, 2.5GbE and USB 3.0 ports, supporting RAID 0, 1, 5, 6, 10 and JBOD

  • TypeDesktop NAS
  • StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
  • Ports1 x 1GbE
  • Port RJ-451 x 2.5GbE + 1 x 1GbE
  • Port USB2 x USB3.0
  • HDD Interface4 x SATA (4 x Bay)

Included HDD Capacity 16TB (4 x 4TB)

Option Fully Populated

  • Ready for heavy workloads with Annapurna AL-524 quad-core processor
  • Faster network transfers via 2.5GbE and 1GbE ports
  • Expand storage easily using two USB 3.0 ports
  • Protect data with RAID 0 1 5 6 10 JBOD
  • 16TB capacity from four 4TB drives included

Ready-to-use 4-bay desktop NAS

The Buffalo TeraStation 3030 TS3430DN1604 arrives with four 4 TB drives pre-installed for 16 TB total capacity. A quad-core Annapurna Labs Alpine AL-524 processor at 2.0 GHz and 2 GB of DDR4 memory handle file serving and RAID management. Small teams or home offices needing immediate shared storage without drive selection can deploy it quickly.

Network and RAID limits

Two RJ-45 ports provide one 2.5 GbE and one 1 GbE link under IEEE 802.3, 802.3u and 802.3ab standards, so aggregate throughput tops out at the 2.5 GbE ceiling. RAID 0, 1, 5, 6, 10 and JBOD are supported, but the single 2.5 GbE uplink will bottleneck sustained sequential transfers before the SATA drives saturate. No 10 GbE or link-aggregation option exists on this model.

Installation notes

Desktop form factor (9.1 x 6.7 x 8.5 in) fits on a shelf; the included 5e ethernet cable and AC cord connect to the rear ports. Drive bays are populated, so initial setup only requires network configuration via the web UI. USB 3.0 ports allow external backup targets. Buyers who want 10 GbE connectivity, ECC memory, or expansion beyond four bays cannot add those later.

Points forts

  • Ready for heavy workloads with Annapurna AL-524 quad-core processor
  • Faster network transfers via 2.5GbE and 1GbE ports
  • Expand storage easily using two USB 3.0 ports
  • Protect data with RAID 0 1 5 6 10 JBOD
  • 16TB capacity from four 4TB drives included

Caractéristiques

BrandBUFFALO
SeriesTeraStation 3030
ModelTS3430DN1604
Part NumberTS3430DN1604
TypeDesktop NAS
StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Ports1 x 1GbE
Port RJ-451 x 2.5GbE + 1 x 1GbE
Port USB2 x USB3.0
HDD Interface4 x SATA (4 x Bay)
Form Factor4-Bay
ProcessorAnnapurna Labs Alpine Processor AL-524 2.0GHz Quad-core
Installed Memory2GB DDR4
Included HDD Capacity16TB (4 x 4TB)
RAIDRAID 0, 1, 5, 6, 10, and JBOD
Drive CompatibilityOP-HD4.0N
Supported ProtocolsTCP/IP
LEDsPower, HDD (Hard Disk Drive), LAN (10/100)
Power100-240 VAC 50/60Hz
Power Consumption33.88W
Temperature0°C - 40 °C
Humidity10-80% Non-condensing
UsageHigh read/write performance with RAID
Dimensions9.1 x 6.7 x 8.5 in
Weight13.7 lbs.
Package ContentsTeraStation, Quick Setup Guide, 5e Ethernet Cable, AC Cable, Front Panel Key, and Warranty Statement
Poids d’expédition7.71 kg
Dimensions du colis363 × 358 × 310 mm

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Should I pick the 16TB 4-bay model or a smaller capacity?

This unit ships with four 4TB drives for 16TB raw capacity; the 4-bay chassis lets you expand later with compatible OP-HD4.0N drives.

What does the 2.5GbE port actually deliver on my network?

The 2.5GbE RJ-45 port supports up to 2.5 Gbps throughput when connected to a 2.5GbE switch or router; the second port runs at 1GbE.

Which network standards limit the 2.5GbE and 1GbE ports?

The ports follow IEEE 802.3, 802.3u and 802.3ab, so the 2.5GbE link is capped at 2.5 Gbps and the 1GbE link at 1 Gbps.
