12-bay rackmount NAS in black metal chassis with front drive bays and rear ports

Buffalo Technology

Buffalo Technology TS71210RH19212 12-bay rackmount NAS 192TB 16GB DDR4

SKU CH-9QXV-RGZBT MPN TS71210RH19212

A 12-bay rackmount NAS with 192 TB of pre-installed enterprise drives and 16 GB DDR4 ECC memory, shipping in RAID 6 for 160 TB usable capacity

  • StandardsIEEE802.3an (10GBASE-T), IEEE802.3bz (5GBASE-T/2.5GBASE-T),
  • Port USB2x USB 3.2 Gen 1 2x USB 2.0
  • PCIe2x PCIe Gen 4x8
  • Installed MemoryDDR4 16GB ECC
  • Included HDD Capacity192TB (12 x 16TB)
  • Drive CompatibilityOP-HDHU2 Series OP-NVSSD Series OP-ECCMEM-16G

Included HDD Capacity 192TB (12 x 16TB)

Option Fully Populated

  • 192 TB raw capacity with 12 enterprise drives included
  • 160 TB usable out of the box in RAID 6
  • Four native 10GbE ports for high-throughput networking
  • Two PCIe Gen 4x8 slots for SSD caching or 25/40GbE cards
  • 16 GB DDR4 ECC memory and Intel Xeon processor for enterprise workloads

12-bay rackmount NAS with 192 TB

The Buffalo TS71210RH19212 is a 12-bay rackmount network-attached storage system pre-populated with twelve 16 TB enterprise-grade hard drives. It ships in RAID 6 configuration providing 160 TB usable capacity and can be reconfigured to RAID 0 for the full 192 TB raw capacity. An Intel Xeon quad-core processor and 16 GB DDR4 ECC memory power the platform for demanding workloads.

Suits IT teams needing high-capacity shared storage

This unit fits organisations that want a ready-to-deploy, high-throughput file server, backup target or application storage platform with native 10 GbE connectivity and PCIe Gen 4 expansion for SSD caching or faster networking. Buyers who require a tower form factor, fewer drive bays, or a lower entry capacity should consider other models.

Ships with 192 TB raw capacity in RAID 6

The twelve included 16 TB drives deliver 192 TB raw storage and are configured out of the box in RAID 6 for 160 TB usable space with dual-drive fault tolerance. This default layout is the single specification that determines whether the available capacity and redundancy match the project requirements.

Points forts

  • 192 TB raw capacity with 12 enterprise drives included
  • 160 TB usable out of the box in RAID 6
  • Four native 10GbE ports for high-throughput networking
  • Two PCIe Gen 4x8 slots for SSD caching or 25/40GbE cards
  • 16 GB DDR4 ECC memory and Intel Xeon processor for enterprise workloads

Caractéristiques

BrandBUFFALO
Part NumberTS71210RH19212
StandardsIEEE802.3an (10GBASE-T), IEEE802.3bz (5GBASE-T/2.5GBASE-T), IEEE802.3ab (1000BASE-T), IEEE802.3u (100BASE-TX), IEEE802.3 (10BASE-T)
Port USB2x USB 3.2 Gen 1
2x USB 2.0
PCIe2x PCIe Gen 4x8
Installed MemoryDDR4 16GB ECC
Included HDD Capacity192TB (12 x 16TB)
Drive CompatibilityOP-HDHU2 Series
OP-NVSSD Series
OP-ECCMEM-16G
RAIDRAID 0, 1, 5, 6, 10, and JBOD
Supported ProtocolsTCP/IP
PowerPower Consumption : Max 500W
Data Transfer 251W
Idling 238W
Power Supply : Internal AC 100-240V
Universal 50/60Hz
Temperature32° - 104°F (0° - 40°C)
Humidity10 - 85% non-condensing
Dimensions29.0 x 18.9 x 3.5 in
Weight54.2 lbs
Package ContentsIncluded Materials :TeraStation, Quick Setup Guide, AC Cable, Front Panel Key, and Warranty Statement
Included Software : NASNavigator2, NovaBACKUP® Buffalo Edition (One server and ten workstation licenses - available for download after product registration)
Additional :For compliance documents such as RoHS Declaration, Certificate of Volatility, Certificate of Conformance, or others please contact [email protected] .
Poids d’expédition30.16 kg
Dimensions du colis978 × 582 × 259 mm

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Will the four 10GbE ports negotiate down to my existing 1GbE switch without a separate adapter?

Yes, the ports support IEEE 802.3ab 1000BASE-T so they will link at 1 Gbps with current Cat5e or Cat6 cabling.

How can I verify the 192 TB array is healthy after the first boot?

Open the web UI, confirm the volume shows RAID 6 with 160 TB usable space, and run a SMART check on all twelve 16 TB drives.

Which items ship inside the box and which drives or memory must be purchased separately?

The box contains the TeraStation, quick setup guide, AC cable, front-panel key and warranty statement; 12 x 16 TB enterprise drives and 16 GB DDR4 ECC are already installed.
