Green circuit board with black controller and silver label, M.2 2280 form factor

Corsair

Corsair Force MP510 960GB M.2 2280 NVMe internal SSD CSSD-F960GBMP510B

SKU CH-M0J7-BM4KW MPN CSSD-F960GBMP510B

960 GB M.2 2280 NVMe SSD delivers up to 3480 MB/s sequential read and 3000 MB/s sequential write with 720 TBW endurance

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity960GB
  • Memory Components3D TLC
  • InterfacePCI-Express 3.0 x4, NVMe 1.3
  • Fast boot and load times with 3480 MB/s sequential read
  • Smooth large-file transfers at 3000 MB/s sequential write
  • Responsive multitasking from 280000 IOPS random read
  • Long service life backed by 720 TBW endurance
  • Data protected by 256-bit AES encryption

Force MP510 960GB NVMe drive

The Corsair Force MP510 is a 960GB internal SSD built on the M.2 2280 form factor. It connects through a PCI-Express 3.0 x4 interface using NVMe 1.3 protocol. The drive targets consumers who want a direct motherboard or notebook installation without extra cables.

Upgrade from hard drives or entry SSDs

Moving to this drive replaces mechanical storage or older solid-state units that top out at lower throughput. The jump is worth it when workloads demand sustained sequential speeds up to 3480 MBps read and 3000 MBps write, plus random performance of 280000 IOPS read and 700000 IOPS write.

960GB capacity with 720 TBW endurance

The 960GB capacity handles operating systems, applications and active project files with comfortable headroom. The 720 TBW rating supports heavy daily writes for years, while the PS5012-E12 controller and 3D TLC NAND maintain consistent performance until the endurance limit is reached.

Points forts

  • Fast boot and load times with 3480 MB/s sequential read
  • Smooth large-file transfers at 3000 MB/s sequential write
  • Responsive multitasking from 280000 IOPS random read
  • Long service life backed by 720 TBW endurance
  • Data protected by 256-bit AES encryption

Caractéristiques

BrandCorsair
SeriesForce MP510
ModelCSSD-F960GBMP510B
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity960GB
Memory Components3D TLC
InterfacePCI-Express 3.0 x4, NVMe 1.3
ControllerPS5012-E12
EncryptionAES 256-bit encryption
Max Sequential ReadUp to 3480 MBps
Max Sequential WriteUp to 3000 MBps
4KB Random ReadUp to 280,000 IOPS
4KB Random WriteUp to 700,000 IOPS
MTBF1,800,000 hours
FeaturesEndrurance: 720 TBW
Extreme Storage Performance: All-new extreme data performance controller delivers up to 3,480 MB/sec sequential read, and up to 3,000 MB/s sequential write, for blazing fast read, write and response times.
High-speed NVMe PCIe Gen3 x4 M.2 Interface: For simple connection and maximum bandwidth.
High-density 3D TLC NAND: Provides the ideal mix of performance, endurance and value to keep your drive performing at its best for years.
Compact M.2 2280 Form Factor: Fits directly into your notebook or motherboard.
Corsair SSD Toolbox Software: Enables advanced drive contr
Power Consumption (Idle)30 mW
Power Consumption (Active)Average Active Read: 6.9W
Average Active Write: 5.6W
Operating Temperature0°C ~ +65°C
Storage Temperature-40°C ~ +85°C
Operating Humidity90% RH (40 celsius degree)
Max Shock Resistance1500G
Max Vibration Resistance20~80 Hz / 1.52mm
Height3.50mm
Width22.00mm
Depth80.00mm
Weight8.20g
Poids d’expédition0.03 kg
Dimensions du colis132 × 71 × 13 mm

Questions sur cet article

Does the M.2 2280 form factor fit a standard motherboard M.2 slot?

The drive uses the M.2 2280 form factor and a PCIe 3.0 x4 NVMe 1.3 interface, so it fits any motherboard or notebook slot wired for PCIe NVMe M.2 2280.

How is the Corsair Force MP510 installed, and what step do people often miss?

Insert the drive at an angle into the M.2 slot, secure it with the motherboard screw, then enable the NVMe controller in BIOS and install the OS or Corsair SSD Toolbox for firmware updates.

What maintenance or replacement should I expect with the 720 TBW endurance rating?

The 3D TLC NAND is rated for 720 TBW and a 1,800,000-hour MTBF; monitor health in Corsair SSD Toolbox and plan replacement once the drive approaches its written endurance limit.
