Silver 1U rack server front with four 3.5-inch drive bays and DVD slot

DELL

DELL PowerEdge R330 1U Rack Server E3-1220 v5 3GHz 8GB 2x 600GB SAS H730 2x 350W

SKU CH-0ZVP-K1PRR

1U rack server with Xeon E3-1220 v5, 8 GB DDR4, dual 600 GB 15K SAS drives, H730 RAID controller and redundant 350 W power supplies

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • MAX Processors1
  • ChipsetIntel C236
  • Quad-core Xeon E3-1220 v5 at 3 GHz delivers responsive compute
  • 8 GB DDR4 memory supports everyday workloads
  • Two 600 GB 15K SAS drives provide fast storage
  • PERC H730 1 GB controller enables RAID 0/1/5/6/10/50/60
  • Dual 350 W hot-swap power supplies keep the server running

1U rack server for small workloads

The Dell PowerEdge R330 fits a single Intel Xeon E3-1220 v5 quad-core processor at 3GHz with 8GB of DDR4 memory. It ships with two 600GB 15K SAS drives on a PERC H730 RAID controller that supports levels 0, 1, 5, 6, 10, 50 and 60. The chassis provides four hot-plug 3.5-inch bays and two PCIe 3.0 expansion slots.

Dual 350W redundant supplies and iDRAC8

Two hot-swap 350W power supplies share the load so a single failure does not shut the system down. The integrated iDRAC8 with Lifecycle Controller gives remote console, power control and hardware inventory over the network. A Matrox G200eR2 video chip with 8MB cache drives local display output when needed.

Rails, bezel and peripherals are not included

The box contains only a power cable; rail kit, front bezel, keyboard, mouse and video cable must be sourced separately. Memory can grow to 64GB across four DIMM slots using 4GB, 8GB or 16GB DDR4 modules up to 2400MT/s. Storage tops out at 40TB across the four drive bays. Networking is limited to two 1GbE ports on the daughter card.

Points forts

  • Quad-core Xeon E3-1220 v5 at 3 GHz delivers responsive compute
  • 8 GB DDR4 memory supports everyday workloads
  • Two 600 GB 15K SAS drives provide fast storage
  • PERC H730 1 GB controller enables RAID 0/1/5/6/10/50/60
  • Dual 350 W hot-swap power supplies keep the server running

Caractéristiques

BrandDELL
SeriesPowerEdge
ModelPowerEdge R330
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
MAX Processors1
ChipsetIntel C236
Installed Memory Size8GB
Memory TypeDDR4
Max Memory Capacity8GB
Memory Features4 DIMM slots compatible with 4GB/8GB/16GB DDR4 up to 2400MT/s, actual memory speed dependent on the processor capability.
Number of Memory Slots4
Storage ControllerDell Perc H730 Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Max HDD Capacity40TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementiDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
LAN Ports2 x Ports
Expansion Slots2 x PCIe 3.0 slots + 1 slot for internal storage.
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight40.0000LBS

Questions sur cet article

How do I install the 3.5" SAS drives in the hot-plug bays, and what step is often missed?

Slide each drive into one of the four 3.5" hot-plug bays until the carrier locks; the step often missed is creating the virtual disk in the H730 controller BIOS before the OS installer can see the volume.

Which components will need replacement first under continuous operation?

The two 600 GB 15K SAS drives and the dual 350 W redundant power supplies are the mechanical parts most likely to require replacement after extended 24/7 use.

What is the first limit reached when the server runs at full load for long periods?

The memory ceiling of 8 GB installed across four DDR4 DIMM slots is the first hard limit encountered during sustained, memory-intensive workloads.
