Silver 2U rack server with front bezel and eight 3.5-inch drive trays

DELL

DELL PowerEdge R540 2U Rack Server 2x Xeon Silver 4114 2.2GHz 256GB DDR4

SKU CH-TA6Q-8N4TT

A 2U rack server with dual 10-core Xeon Silver 4114 CPUs at 2.2 GHz, 256 GB DDR4, PERC H730P RAID controller, eight 3.5-inch drive trays, iDRAC9 Enterprise and redundant 750 W power supplies

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.20 GHz
  • CPU SocketLGA 3647
  • Dual 10-core Xeon 4114 CPUs reach 3.0 GHz turbo for demanding workloads
  • 256 GB DDR4 2666 MHz ECC memory scales to 384 GB across 16 slots
  • PERC H730P RAID controller supports RAID 0/1/5/6/10/50/60 with 2 GB cache
  • Eight 3.5" SAS/SATA drive bays provide flexible storage capacity
  • iDRAC 9 Enterprise and dual 750 W platinum PSUs enable remote management and power redundancy

Dual Xeon Silver 4114 2U Server

The Dell PowerEdge R540 is a 2U rack server equipped with two Intel Xeon Silver 4114 processors, each running at 2.2 GHz with a 3.0 GHz turbo frequency. It ships with 256 GB of DDR4 registered ECC memory installed across 16 DIMM slots and includes a PERC H730P storage controller with 2 GB cache. Dual redundant 750 W power supplies, iDRAC9 Enterprise remote management, and ready rails with a front bezel complete the chassis.

Virtualisation and Database Hosts

This configuration suits organisations deploying virtualisation clusters, database servers, or file and application workloads that benefit from 20 total cores and large memory capacity. The eight 3.5-inch SAS/SATA drive bays provide internal storage flexibility without pre-installed drives. Buyers who need more than 384 GB of memory or require additional processor sockets should look at larger platforms.

PERC H730P RAID Controller

The installed Dell PERC H730P 2 GB controller determines which drive types and RAID levels are supported. It handles SAS and SATA drives with RAID 0, 1, 5, 6, 10, 50, 60 and pass-through modes. Verify that your intended drives and redundancy scheme are compatible with this controller before purchase.

Points forts

  • Dual 10-core Xeon 4114 CPUs reach 3.0 GHz turbo for demanding workloads
  • 256 GB DDR4 2666 MHz ECC memory scales to 384 GB across 16 slots
  • PERC H730P RAID controller supports RAID 0/1/5/6/10/50/60 with 2 GB cache
  • Eight 3.5" SAS/SATA drive bays provide flexible storage capacity
  • iDRAC 9 Enterprise and dual 750 W platinum PSUs enable remote management and power redundancy

Caractéristiques

BrandDELL
SeriesPowerEdge R740
ModelR540
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.20 GHz
CPU SocketLGA 3647
Number of CPU Cores10-Core Processor
# of Processors Installed2
MAX Processors2
Chipset0
Installed Memory Size256GB
Memory Type0
Max Memory Capacity384GB
Number of Memory Slots16
Hard Drive (Installed)None
Storage ControllerDell Perc H730P 2GB Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media Drives0
GPU Type0
Video Memory0
Ethernet ControllerIntegrated Dell 2x1GbE Dual Port Ethernet Adapter
LAN Ports2 x Ports
Expansion Slots0
Management Port0
Operating SystemNo
Features8 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions sur cet article

What RAID levels does the H730P 2GB controller support?

The PERC H730P 2GB controller supports RAID 0, 1, 5, 6, 10, 50 and 60 as well as pass-through mode for non-RAID configurations.

What are the physical mounting requirements for this 2U server?

The server is a 2U rackmount chassis that includes ready rails and a front bezel for installation in a standard rack enclosure.

How are the processors installed and what is a common mistake?

Two Xeon Silver 4114 CPUs come pre-installed in the LGA 3647 sockets; a common error is adding a third processor when the maximum is two.
