Silver 2U rack server front with eight 2.5-inch drive bays and bezel

DELL

DELL PowerEdge R730 2U rack server 2x Xeon E5-2620 v3 2.4GHz 64GB DDR4 H730 2x 300GB SAS

SKU CH-TV3C-TSPP8

2U rack server with dual 6-core Xeon CPUs, 64GB DDR4 ECC memory, PERC H730 RAID controller, two 300GB 10K SAS drives, quad-port 1GbE and 10GbE SFP+ networking, iDRAC8 Enterprise.

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.40 GHz
  • CPU SocketLGA 2011-3

Installed Memory Size 64GB

HDD 2 x 300GB 10K SAS

  • Dual Xeon E5-2620 v3 at 2.4 GHz with 3.2 GHz turbo for strong multi-threaded performance
  • 64 GB DDR4 2133 MHz registered ECC memory supports up to 1.5 TB capacity
  • PERC H730 1 GB controller enables RAID 0, 1, 5, 6, 10, 50, 60 with battery backup
  • Quad-port X520/I350 delivers two 1 GbE and two 10 Gb SFP+ connections
  • iDRAC 8 Enterprise provides full remote management with dual 750 W platinum power supplies for redundancy

Purpose-built 2U rack server

The Dell PowerEdge R730 is a 2U rack server equipped with two Intel Xeon E5-2620 v3 processors, each running at 2.40 GHz with six cores. It ships with 64 GB of DDR4 2133 MHz registered ECC memory across four modules and includes a PERC H730 storage controller with 1 GB cache. Two 300 GB 10K SAS drives and a quad-port network daughter card with two 1 GbE and two 10 Gb SFP+ ports are installed. iDRAC 8 Enterprise provides remote management.

Thermals noise and power draw

Dual 750 watt platinum-efficiency power supplies deliver redundant hot-swap power for continuous operation. The 2U chassis uses managed airflow across the processors, memory and drive bays to maintain thermal stability under load. Fan speeds scale with inlet temperature and component utilisation, keeping acoustic output appropriate for a data-centre environment rather than a quiet office.

Included accessories and management

Ready rails and a front bezel are supplied for immediate rack mounting. The PERC H730 controller supports RAID 0, 1, 5, 6, 10, 50 and 60 plus pass-through, enabling flexible storage configurations across the eight 2.5 inch bays. iDRAC 8 Enterprise adds a dedicated management network port, virtual console, remote media and lifecycle automation without requiring an additional licence.

Points forts

  • Dual Xeon E5-2620 v3 at 2.4 GHz with 3.2 GHz turbo for strong multi-threaded performance
  • 64 GB DDR4 2133 MHz registered ECC memory supports up to 1.5 TB capacity
  • PERC H730 1 GB controller enables RAID 0, 1, 5, 6, 10, 50, 60 with battery backup
  • Quad-port X520/I350 delivers two 1 GbE and two 10 Gb SFP+ connections
  • iDRAC 8 Enterprise provides full remote management with dual 750 W platinum power supplies for redundancy

Caractéristiques

BrandDELL
SeriesPowerEdge R730
ModelR730
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.40 GHz
CPU SocketLGA 2011-3
Number of CPU Cores6-Core Processor
# of Processors Installed2
MAX Processors2
ChipsetIntel C610
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity1.5TB
Number of Memory Slots24
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features8 x 2.5" SATA/SAS Hot-Plug Drive Bays

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

How do I install the server into a rack and which rail step is often missed?

Mount the included ReadyRails into a 2U space, slide the chassis onto the rails until it locks, then secure the front bezel; the step often missed is engaging the rear rail latches before pushing the server fully home.

What component will need replacement first during long-term operation?

The two 750 W platinum power supplies and the PERC H730 controller battery are the field-replaceable parts most likely to require service after extended use.

What thermal or power limit appears first when the dual 2.4 GHz Xeons run at 3.2 GHz turbo continuously?

The 750 W redundant PSU rating and the 2U chassis airflow ceiling cap sustained turbo operation before CPU thermal throttling activates.
