Silver 2U rack server with twelve 3.5-inch drive bays visible at the front

DELL

DELL PowerEdge R730XD 2U rack server 2x E5-2609v3 1.9GHz 16GB DDR4 3x 300GB SAS H730

SKU CH-Y853-B2XWB

2U rack server with dual Xeon E5-2609v3 processors, 16GB DDR4, three 300GB 15K SAS drives and a Perc H730 RAID controller supporting up to 12 hot-plug bays

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeDual Intel Xeon
  • MAX Processors2
  • ChipsetIntel C610

Installed Memory Size 16GB

Les versions barrées existent, mais ne sont pas disponibles ici.

HDD 3 x 300GB 15K

Les versions barrées existent, mais ne sont pas disponibles ici.

  • Dual Xeon six-core CPUs deliver 12 total threads for parallel workloads
  • 16 GB DDR4 memory installs in 24 DIMM slots for future expansion
  • Three 300 GB 15K SAS drives provide fast hot-plug storage
  • H730 RAID controller supports RAID 0, 1, 5, 6, 10, 50, 60
  • Dual 750 W redundant power supplies keep the 2U server running

Rack server with twelve 3.5-inch bays

The Dell PowerEdge R730XD is a 2U rack server built for storage-heavy workloads. It ships with two Intel Xeon E5-2609 v3 six-core processors running at 1.9 GHz and 16 GB of DDR4 memory across 24 DIMM slots. Three 300 GB 15 000 RPM SAS drives and a PERC H730 RAID controller with 1 GB cache are installed, supporting RAID levels 0, 1, 5, 6, 10, 50 and 60. Dual 750 W redundant power supplies and a DVD ROM complete the configuration.

Suits dense storage; not for large memory

This server fits environments that need up to twelve hot-plug 3.5-inch SAS or SATA drives in a compact chassis, such as backup repositories, archiving or software-defined storage nodes. The installed CPUs provide twelve total cores at a modest clock speed, so compute-intensive applications will be limited. Buyers who need more than sixteen gigabytes of memory or who require drive interfaces beyond SAS and SATA should look elsewhere, as the current controller and chassis do not support those configurations.

PERC H730 RAID controller

The single specification that decides fit is the combination of the PERC H730 controller and the twelve-bay 3.5-inch SAS backplane. This pairing defines the maximum raw capacity of 52 TB, the supported RAID levels and the drive types the server can accept. If your deployment requires a different controller feature set, a 2.5-inch form factor or a drive protocol not listed here, this chassis will not meet the requirement.

Points forts

  • Dual Xeon six-core CPUs deliver 12 total threads for parallel workloads
  • 16 GB DDR4 memory installs in 24 DIMM slots for future expansion
  • Three 300 GB 15K SAS drives provide fast hot-plug storage
  • H730 RAID controller supports RAID 0, 1, 5, 6, 10, 50, 60
  • Dual 750 W redundant power supplies keep the 2U server running

Caractéristiques

BrandDELL
SeriesPowerEdge
ModelPowerEdge R730XD
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeDual Intel Xeon
MAX Processors2
ChipsetIntel C610
Installed Memory Size16GB
Memory TypeDDR4
Max Memory Capacity16GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots24
Storage ControllerDell Perc H730 Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Max HDD Capacity52TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementiDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
LAN Ports4 x Ports
Expansion SlotsUp to 7 x PCIe 3.0 plus dedicated PERC slot
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight70.0000LBS

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

What RAID levels does the H730 controller support?

The H730 controller supports RAID 0, 1, 5, 6, 10, 50, and 60 across the installed 300GB 15K SAS drives and any additional hot-plug drives.

How many 3.5-inch drive bays does the 2U chassis provide?

The chassis provides up to 12 hot-plug 3.5-inch bays, with trays included for the three factory-installed 300GB SAS drives.

How is the H730 RAID controller installed in the R730XD?

The H730 occupies the dedicated internal RAID card slot, leaving all six PCIe 3.0 expansion slots free for other cards.
