Silver 2U rack server chassis with 24 front drive bays, dual power supplies, DVD drive, and rack ears

DELL

DELL PowerEdge R730XD 2U rack server E5-2630 v3 2.4GHz 64GB 3x 1TB H730

SKU CH-6HTC-7KRAS

2U rack server with single Xeon E5-2630 v3, 64GB DDR4, three 1TB SATA drives and H730 RAID controller

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • MAX Processors2
  • ChipsetIntel C610

Installed Memory Size 64GB

HDD 3 x 1TB

  • Eight-core Xeon E5-2630 v3 at 2.4 GHz for multi-threaded workloads
  • 64 GB DDR4 memory in 24 slots for high-capacity virtualisation
  • Three 1 TB 7.2K SATA drives on H730 RAID controller for protected storage
  • Dual 750 W redundant hot-swap power supplies for continuous uptime
  • 24 hot-plug 2.5-inch bays in 2U rack form factor for dense expansion

Dell PowerEdge R730XD 2U rack server

The Dell PowerEdge R730XD is a 2U rack server built around a single Intel Xeon E5-2630 v3 eight-core processor running at 2.4 GHz. It ships with 64 GB of DDR4 memory and three 1 TB 7.2K SATA drives managed by a PERC H730 RAID controller with 1 GB cache. Dual 750 W redundant power supplies and 24 hot-plug 2.5-inch drive bays complete the platform.

Ideal for storage-dense workloads and virtualisation

This configuration suits buyers who need high drive-count density in a 2U form factor with hardware RAID 0, 1, 5, 6, 10, 50 or 60. It is not for buyers who require two processors installed or more than 64 GB of memory from the factory, as the system arrives with one CPU and the memory ceiling with a single processor is 64 GB.

Single-processor memory ceiling of 64 GB

The installed CPU limits total addressable memory to 64 GB across the 24 DIMM slots, so the server cannot accept additional RAM unless a second processor is added. This constraint decides whether the chassis can grow with your workload or must be replaced.

Points forts

  • Eight-core Xeon E5-2630 v3 at 2.4 GHz for multi-threaded workloads
  • 64 GB DDR4 memory in 24 slots for high-capacity virtualisation
  • Three 1 TB 7.2K SATA drives on H730 RAID controller for protected storage
  • Dual 750 W redundant hot-swap power supplies for continuous uptime
  • 24 hot-plug 2.5-inch bays in 2U rack form factor for dense expansion

Caractéristiques

BrandDELL
SeriesPowerEdge
ModelPowerEdge R730XD
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
MAX Processors2
ChipsetIntel C610
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity64GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots24
Storage ControllerDell Perc H730 Controller
HDD InterfaceSATA
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Max HDD Capacity52TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementiDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
LAN Ports4 x Ports
Expansion SlotsUp to 7 x PCIe 3.0 plus dedicated PERC slot
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight70.0000LBS

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Should I choose the single E5-2630 v3 or add a second processor?

The board supports up to two Xeon CPUs; a second E5-2630 v3 doubles cores to 16 and unlocks the remaining 12 DIMM slots for memory beyond 64GB.

What does the 2.4 GHz clock mean for actual throughput?

Each of the eight cores runs at 2.4 GHz with Hyper-Threading giving 16 threads; real-world speed depends on workload and the DDR4 memory running up to 2400 MT/s.

How does the 12 Gbps H730 controller limit the 6 Gbps SATA drives?

The H730 supports 12 Gbps SAS and 6 Gbps SATA; the installed 1 TB drives operate at their native 6 Gbps link, so the controller does not reduce their speed.
