Silver 2U rack server with 24 front drive bays, front bezel and sliding rails

DELL

DELL PowerEdge R750 24x 2.5" 2U rack server 2x Xeon Gold 5317 3.0GHz 12C 128GB DDR4 H755

SKU CH-YTSZ-1XKQZ

2U rack server with dual Xeon Gold 5317 processors, 128GB DDR4, PERC H755 RAID controller, 24-bay 2.5" SATA/SAS storage and dual 1400W power supplies

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed3.00 GHz
  • CPU SocketLGA 4189
  • Dual Xeon Gold 5317 CPUs deliver 24 cores at 3.0 GHz base
  • 128 GB DDR4 2933 MHz ECC memory across 8 modules
  • PERC H755 RAID controller with 8 GB NV cache supports RAID 0/1/5/6/10/50/60
  • 24 front-access 2.5" SAS/SATA drive trays for dense storage
  • iDRAC9 Enterprise plus dual 1400 W platinum PSUs for remote management and power redundancy

Dell PowerEdge R750 2U rack server

The Dell PowerEdge R750 is a 2U rack server built for enterprise workloads. It ships with two Intel Xeon Gold 5317 processors running at 3.0 GHz with 12 cores each. The system includes 128 GB of DDR4 registered ECC memory across eight 16 GB modules. A PERC H755 RAID controller with 8 GB NV cache and battery backs the 24 front-accessible 2.5-inch drive trays.

Suits dense compute and virtualization.

This configuration fits buyers who need high core counts and large memory in a compact 2U form factor. The 24-bay 2.5-inch chassis supports SAS and SATA drives with hardware RAID 0, 1, 5, 6, 10, 50 and 60. Dual 10 GbE SFP+ ports and iDRAC9 Enterprise provide remote management and fast networking. Buyers who need 3.5-inch drive bays, internal GPU acceleration, or more than two processors should evaluate other platforms.

24-bay 2.5-inch chassis with PERC H755 RAID

The single specification that decides fit is the 24-bay 2.5-inch chassis paired with the PERC H755 controller. It accepts SAS and SATA SSDs or HDDs and supports RAID levels up to 60. The H755’s 8 GB NV cache with battery protects writes during power loss. If your deployment requires 3.5-inch drives, NVMe U.2 backplanes, or a different RAID feature set, this chassis and controller combination will not meet those requirements.

Points forts

  • Dual Xeon Gold 5317 CPUs deliver 24 cores at 3.0 GHz base
  • 128 GB DDR4 2933 MHz ECC memory across 8 modules
  • PERC H755 RAID controller with 8 GB NV cache supports RAID 0/1/5/6/10/50/60
  • 24 front-access 2.5" SAS/SATA drive trays for dense storage
  • iDRAC9 Enterprise plus dual 1400 W platinum PSUs for remote management and power redundancy

Caractéristiques

BrandDELL
SeriesPowerEdge R750
ModelR750
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed3.00 GHz
CPU SocketLGA 4189
Number of CPU Cores12-Core Processor
CPU FeaturesGold 5317
# of Processors Installed2
MAX Processors2
Chipset0
Installed Memory Size128GB
Memory TypeDDR4
Max Memory Capacity0
Number of Memory Slots32
Storage ControllerDell Perc H755 Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Max HDD CapacityNone
Media Drives0
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell EMC 15G Broadcom 57412 Dual Port 10GbE SFP+ OCP 3.0 Network Card
LAN Ports2 x Ports
Expansion Slots0
Management PortRJ 45
Operating SystemNo
Features24 x 2.5" SATA/SAS Hot-Plug Drive Bays

Questions sur cet article

How many 2.5-inch drive trays does the R750 include?

The chassis provides 24 front-accessible trays that accept both SAS and SATA solid-state or hard-disk drives.

What turbo frequency can the dual Xeon Gold 5317 processors reach under load?

Each 12-core CPU has a 3.6 GHz maximum turbo frequency, giving 24 total cores for multi-threaded workloads.

Which RAID levels are supported by the integrated PERC H755 controller?

The H755 supports RAID 0, 1, 5, 6, 10, 50 and 60 with its 8 GB non-volatile cache and battery backup.
