Tall silver rack server front with sixteen drive bays and Dell badge

DELL

DELL PowerEdge T430 5U rack server 2x Xeon E5-2695 v4 2.1GHz 18C 32GB DDR4 H730P 4x 960GB SSD

SKU CH-8A6D-344F3

5U tower server with dual 18-core Xeon processors at 2.1GHz, 32GB DDR4, H730P RAID controller and four 960GB SSDs

  • TypeRack
  • Rack Height5U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.1GHz (3.3GHz Turbo)
  • CPU SocketLGA 2011
  • Dual 18-core Xeon processors at 2.1 GHz with 3.3 GHz turbo
  • 32 GB DDR4-2400 ECC memory expandable to 384 GB across 12 slots
  • PERC H730P 2 GB controller supports RAID 0, 1, 5, 6, 10, 50, 60
  • Four 960 GB enterprise SATA SSDs installed in 16-bay 2.5-inch chassis
  • Redundant 750 W platinum power supplies with iDRAC 8 Express remote management

Dual Xeon E5-2695 v4 18-core server

The Dell PowerEdge T430 is a 5U tower server equipped with two Intel Xeon E5-2695 v4 processors, each running at 2.1 GHz with 3.3 GHz turbo and 18 cores. It ships with 32 GB of DDR4-2400 ECC registered memory across four modules and a PERC H730P storage controller with 2 GB cache. Four 960 GB SATA SSDs are installed in the 16-bay 2.5-inch hot-swap chassis.

Redundant 750 W platinum power supplies

Two hot-plug 750 watt platinum-efficiency power supplies provide full redundancy for continuous operation. The 5U form factor allows generous airflow through the front drive bays and across the dual processor sockets. Integrated iDRAC 8 Express enables remote monitoring of thermal sensors and fan speeds without requiring a dedicated management port.

16-bay hot-swap chassis with PERC H730P

The front panel accepts up to sixteen 2.5-inch SAS or SATA drives, while the H730P controller supports RAID 0, 1, 5, 6, 10, 50 and 60 plus pass-through mode. Dual 1 GbE ports and PCI Express expansion slots handle networking and additional controllers. Memory capacity can grow to 384 GB across twelve DDR4 slots, and the system supports a maximum of two processors. Front bezel and rack rails are not included.

Points forts

  • Dual 18-core Xeon processors at 2.1 GHz with 3.3 GHz turbo
  • 32 GB DDR4-2400 ECC memory expandable to 384 GB across 12 slots
  • PERC H730P 2 GB controller supports RAID 0, 1, 5, 6, 10, 50, 60
  • Four 960 GB enterprise SATA SSDs installed in 16-bay 2.5-inch chassis
  • Redundant 750 W platinum power supplies with iDRAC 8 Express remote management

Caractéristiques

BrandDELL
SeriesPowerEdge
ModelT430
TypeRack
Rack Height5U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.1GHz (3.3GHz Turbo)
CPU SocketLGA 2011
Number of CPU Cores18 Core-Processors
CPU FeaturesE5-2695 v4
# of Processors Installed2
MAX Processors2
Installed Memory Size32GB
Memory TypeDDR4
Max Memory Capacity384GB
Number of Memory Slots12
Hard Drive (Installed)None
Storage ControllerDell Perc H730P 2GB Controller
HDD InterfaceSATA
SSD (Installed)4 x 960GB SATA SSD
Raid LevelRAID 0/1/5/6/10/50/60
Ethernet ControllerIntegrated Dell 2x1GbE Dual Port Ethernet Adapter
Remote ManagementiDRAC8 Express
LAN Ports2 x Ports
Management PortRJ 45
Operating SystemNo

Questions sur cet article

How do I install the 2.5-inch SSDs into the 16-bay front chassis, and which step is often missed?

Slide each drive into a hot-swap bay until the latch clicks; the step often missed is seating the latch fully so the controller detects the SSD.

Which component will need replacement first under continuous operation?

The PERC H730P controller battery backs the write cache; it typically requires replacement after several years of 24/7 use.

What thermal limit appears first when both 18-core Xeons run at 3.3 GHz Turbo for extended periods?

The 750 W platinum power supplies set the sustained power ceiling; prolonged all-core Turbo can hit that limit before CPU throttling activates.
