DELL PowerEdge T630 18LFF 2x Xeon E5-2699v4 32GB DDR4 No Drive Rack Server
Eighteen 3.5-inch drive bays, dual 2.2 GHz Xeon E5-2699 v4 processors with 22 cores each, 32 GB DDR4 ECC memory and a PERC H730 RAID controller in a rack-mount chassis
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.2GHz
- # of Processors Installed2
- MAX Processors2
- Installed Memory Size32GB
- Dual Xeon E5-2699 v4 processors deliver 22 cores each at 2.2GHz
- 32GB DDR4 ECC registered memory installed with capacity up to 1.5TB
- 18 bays for 3.5" SATA drives backed by PERC H730 SAS controller
- iDRAC8 Enterprise licence enables full remote server management
- Dual 1100W power supplies provide redundant power for uptime
Server chassis and processors
The Dell PowerEdge T630 arrives in an 18-bay 3.5-inch rack-mount chassis with two Intel Xeon E5-2699 v4 processors installed. Each CPU runs at 2.2 GHz and provides 22 cores with 55 MB of cache. The system includes 32 GB of DDR4 ECC registered memory configured as two 16 GB modules.
Storage interface and expansion limits
The PERC H730 SAS controller manages up to 18 SATA or SAS drives in the front bays; no drives are installed from the factory. Maximum supported memory reaches 1.5 TB across the available DIMM slots. Dual 1100 W power supplies and a 1 GbE two-port 332T network adapter are fitted, while iDRAC8 Enterprise enables remote management.
Pre-order compatibility checks
Verify that your rack can accommodate the 36 x 24 x 10 inch form factor and 40 kg weight before ordering. Confirm the SAS or SATA drive types you intend to populate and ensure the H730 firmware matches your RAID requirements. Rail kits are available on request if your cabinet uses non-standard mounting.
Points forts
- Dual Xeon E5-2699 v4 processors deliver 22 cores each at 2.2GHz
- 32GB DDR4 ECC registered memory installed with capacity up to 1.5TB
- 18 bays for 3.5" SATA drives backed by PERC H730 SAS controller
- iDRAC8 Enterprise licence enables full remote server management
- Dual 1100W power supplies provide redundant power for uptime
Caractéristiques
| Brand | DELL |
|---|---|
| Series | PowerEdge |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.2GHz |
| # of Processors Installed | 2 |
| MAX Processors | 2 |
| Installed Memory Size | 32GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 1.5TB |
| Hard Drive (Installed) | 2,00 |
| Storage Controller | Dell PERC H730 SAS Controller |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | iDRAC8 - Enterprise License |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
