Dell Precision T5820 Tower Workstation Xeon W-2133 64GB DDR4 1TB NVMe Quadro P5000 Windows 11 Pro

Dell Precision T5820 Workstation

The Dell Precision T5820 Tower is a new mid-tower workstation built around an Intel Xeon W-2133 six-core processor running at 3.6 GHz with a 3.9 GHz turbo. It ships with 64 GB of DDR4 2666 registered ECC memory across eight slots, a 1 TB PCIe NVMe solid-state drive, and an Nvidia Quadro P5000 graphics card with 16 GB GDDR5X memory and four DisplayPort outputs. Windows 11 Pro is pre-installed and digitally activated.

Build integration and expandability

The LGA 2066 platform supports up to 256 GB of DDR4 2666 ECC memory, leaving four DIMM slots open for future upgrades. A 950 W 80 Plus Gold power supply rated at 90 % efficiency delivers headroom for additional storage or expansion cards. Gigabit Ethernet via the Intel i219 controller and integrated Realtek ALC3234 high-definition audio are onboard, so no extra networking or sound cards are required for typical professional workflows.

Upgrade context and fit

This system replaces an older single-socket workstation that maxes out below 256 GB of memory or lacks native NVMe boot support. The six-core Xeon and Quadro P5000 combination suits engineers and content creators who need certified drivers and 16 GB of professional GPU memory but do not require dual-socket scaling. Buyers who need more than 256 GB of RAM or multiple high-wattage GPUs should look at larger chassis platforms.
