Silver 2U rack server with eight front drive bays

HP

HP ProLiant DL380 Gen9 2U rack server 2× Xeon E5-2630 v3 8GB 2× 146GB SAS H240ar

SKU CH-A53W-PNESZ

A 2U rack server with dual eight-core Xeon processors at 2.4GHz, 8GB DDR4 memory, two 146GB 15K SAS drives and an H240ar RAID controller

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon E5 v3
  • MAX Processors2
  • ChipsetIntel C610
  • Dual Xeon E5-2630 v3 CPUs deliver 16 cores at 2.4 GHz
  • 8 GB DDR4 ECC memory with 24 slots for expansion up to 3 TB
  • Two 146 GB 15K SAS drives provide fast 2.5-inch storage
  • Smart HBA H240ar supports RAID 0/1/5/6/10/50/60 on 12 Gb SAS
  • Redundant hot-swap 500 W power supplies ensure continuous operation

2U rack server for virtualised workloads

The HP ProLiant DL380 Gen9 is a 2U rackmount server built for data-centre deployment. Dual Intel Xeon E5-2630 v3 processors provide 16 physical cores and 32 threads for multi-tenant applications. Redundant hot-swap 500 W power supplies and an 8-bay small-form-factor chassis support continuous operation.

Suits consolidation and database tiers.

This configuration fits organisations consolidating virtual machines or running memory-hungry databases with local SAS storage. The integrated Matrox G200eH2 graphics and lack of PCIe accelerator support make it unsuitable for workloads that require GPU acceleration or high-performance visualisation.

24 DDR4 DIMM slots define expansion ceiling

Twenty-four registered DDR4 slots, twelve per processor, set the practical memory ceiling for this platform. Buyers planning large in-memory datasets must budget for additional DIMMs to move beyond the 8 GB factory configuration.

Points forts

  • Dual Xeon E5-2630 v3 CPUs deliver 16 cores at 2.4 GHz
  • 8 GB DDR4 ECC memory with 24 slots for expansion up to 3 TB
  • Two 146 GB 15K SAS drives provide fast 2.5-inch storage
  • Smart HBA H240ar supports RAID 0/1/5/6/10/50/60 on 12 Gb SAS
  • Redundant hot-swap 500 W power supplies ensure continuous operation

Caractéristiques

BrandHP
SeriesProLiant
ModelProliant DL380 G9
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon E5 v3
MAX Processors2
ChipsetIntel C610
Installed Memory Size8GB
Memory TypeDDR4
Max Memory Capacity8GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s ECC Registered, actual memory speed dependent on the processor capability).
Number of Memory Slots24
Storage ControllerHP Smart HBA H240ar Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media DrivesNone
GPU TypeMatrox G200eH2
Video Memory16MB
Remote ManagementiLO Management (standard).
LAN Ports4 x Ports
Expansion SlotsPrimary Riser: 3 PCIe 3.0 Slots (1-3) available: 2x Full-Height Half Length, 1x Half-Lenth Full Height. Optional 3 additional slots (Slot 2 PCIe Riser and dual CPU required).
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight63.0000LBS

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

What SAS speed does the H240ar controller support, and how does that cap drive throughput?

The Smart HBA H240ar provides 12Gb SAS and 6Gb SATA connectivity; installed 146GB drives run at 6Gbps, so the controller does not limit their maximum throughput.

What physical space and bay layout does the 2U chassis require for drives and media?

The chassis occupies 2U of rack height and includes 8 SFF 2.5-inch bays; a universal media bay can be added to bay 3 and NVMe or extra SFF bays to bay 2.

How are the redundant power supplies installed, and what step is often missed?

Two 500W hot-swap power supplies slide into the rear bays; the step often missed is connecting both units to separate PDUs or circuits for true redundancy.
